Question 5 Problem Definition Write a MATLAB script that uses nested loops to create a 100 by 100 element 2D array representing an image that shades from white at the image edges to black in the image centre (see image below). Your script should save the image in a file called test5.png. Testing The image file produced should shade from white at the image edges to black in the image centre. Any image that graduates colour continuously from light at the edges to black in the centre is acceptable. An image that comes from one simple implementation is: Coding You can implement this code by making the pixel intensity increase with distance from the centre of the image. Think of how you might measure this distance for rows and columns. Write your code in a MATLAB script called q5.m and save it into your week4practice folder.
Added by Benjamin R.
Close
Step 1
Step 1: Create a 100 by 100 matrix to represent the image. Show more…
Show all steps
