Question One Water is to be transported from one tank to another using a 10 m pipeline of inside
diameter 25 mm. A centrifugal pump is to be used to transport the water and is
positioned below the first tank whose free surface is 2 m above the freely discharging outlet. Determine the duty point for the pump characteristic given below. The fanning friction factor may be assumed to be 0.005.Allow for entrance and exit loses
Discharge,m'min 0000 0.0080.0120.0180.024
Head, m
3.5
3.2
3.0
2.4
1.4
