Question 13 A second order control system has a damping factor of 0.9. What is the percent overshoot for unit step input?
Added by Marc C.
Close
Step 1
The damping factor (ξ) is defined as the ratio of the actual damping coefficient (c) to the critical damping coefficient (cc). ξ = c / cc For a second-order system, the critical damping coefficient (cc) is given by: cc = 2 * sqrt(k * m) where k is the spring Show more…
Show all steps
