QUESTION 3 Which of the following statements is false? A. An Exclusive-OR output is 1 (HIGH) when the inputs are at the same levels. B. An OR gate output is 1 (HIGH) when one or more inputs are 1 (HIGH). C. A NOR output is 1 (HIGH) only when all inputs are 0 (LOW). D. Apply the bits to the Exclusive-OR inputs; when the output is 1 (HIGH), the bits are different. QUESTION 4 Which of the following IC logic designators is false? A. AC - Alternative Current CMOS B. HC - High-speed CMOS C. LV - Low-voltage CMOS D. F - Fast TTL E. ALS - Advanced LS F. LS - Low-power Schottky

          QUESTION 3
Which of the following statements is false?
A. An Exclusive-OR output is 1 (HIGH) when the inputs are at the same levels.
B. An OR gate output is 1 (HIGH) when one or more inputs are 1 (HIGH).
C. A NOR output is 1 (HIGH) only when all inputs are 0 (LOW).
D. Apply the bits to the Exclusive-OR inputs; when the output is 1 (HIGH), the bits are different.
QUESTION 4
Which of the following IC logic designators is false?
A. AC - Alternative Current CMOS
B. HC - High-speed CMOS
C. LV - Low-voltage CMOS
D. F - Fast TTL
E. ALS - Advanced LS
F. LS - Low-power Schottky

Show more…

QUESTION 3
Which of the following statements is false?
A. An Exclusive-OR output is 1 (HIGH) when the inputs are at the same levels.
B. An OR gate output is 1 (HIGH) when one or more inputs are 1 (HIGH).
C. A NOR output is 1 (HIGH) only when all inputs are 0 (LOW).
D. Apply the bits to the Exclusive-OR inputs; when the output is 1 (HIGH), the bits are different.
QUESTION 4
Which of the following IC logic designators is false?
A. AC - Alternative Current CMOS
B. HC - High-speed CMOS
C. LV - Low-voltage CMOS
D. F - Fast TTL
E. ALS - Advanced LS
F. LS - Low-power Schottky

Added by Hugo S.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Pranay Shrivastava

Step 1

An Exclusive-OR output is high when the inputs are at the same levels. - This statement is true. The output of an XOR gate is high when the inputs are at different levels. B. An OR gate output is high when any input is high. - This statement is true. The output of Show more…
