Replace the three forces shown by an equivalent force-couple system at point A. If the forces are replaced by a single resultant force, determine the distance d below point A to its line of action. 200 N 790 mm A 790 mm 180 N 790 mm 330 N Answers: Force-couple system at A. The force is positive if to the right, and the couple is positive if counterclockwise. R = N M = N·m Single resultant force. d = mm

          Replace the three forces shown by an equivalent force-couple system at point A. If the forces are replaced by a single resultant force, determine the distance d below point A to its line of action.
200 N
790 mm
A
790 mm
180 N
790 mm
330 N
Answers:
Force-couple system at A. The force is positive if to the right, and the couple is positive if counterclockwise.
R =
N
M =
N·m
Single resultant force.
d =
mm

Show more…

Replace the three forces shown by an equivalent force-couple system at point A. If the forces are replaced by a single resultant force, determine the distance d below point A to its line of action.
200 N
790 mm
A
790 mm
180 N
790 mm
330 N
Answers:
Force-couple system at A. The force is positive if to the right, and the couple is positive if counterclockwise.
R =
N
M =
N·m
Single resultant force.
d =
mm

Added by Carol H.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Supreeta N

06/02/2023

Step 1

Step 1: Calculate the resultant force (R) R = 200 N (right) - 180 N (left) + 330 N (right) R = 350 N (right) Show more…

Show all steps

lock

Thanks for your feedback!

Replace the three forces shown by an equivalent force-couple system at point A. If the forces are replaced by a single resultant force, determine the distance d below point A to its line of action.

Play audio

Feedback

Powered by NumerAI

Supreeta N and 85 other subject Physics 101 Mechanics educators are ready to help you.

Ask a new question

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Recommended Videos

Recommended Textbooks

Transcript

00:01 Hello students, in the question we are given three forces, we have to find equivalent force couple system at point a.

00:08 We can move these forces at point a.

00:10 We are moving 200 newton force at point a.

00:15 So, corresponding to this we also have moment.

00:17 This 200 newton force causes a clockwise moment.

00:21 So, here we have clockwise moment m1, m1 it is equal to force that is 200 newton into distance from point a that is 0 .79 meters.

00:35 This comes out to be equal to minus 158 newton meter.

00:41 Next, we are moving this force at point a.

00:45 So, here we have force 180 newton.

00:49 Now, this force also causes clockwise moment.

00:53 So, here we would have clockwise moment m2, m2 is equal to force that is 180 newton into distance from point a that is 0 .79 meters.

01:08 This is equal to minus 142 .2 newton meter.

01:13 We have third force 330 newton.

01:16 Here we can move this force also here at point a, 330 newton.

01:22 This force causes counterclockwise moment.

01:25 Here we have counterclockwise moment due to this force.

01:31 We have m3, it is equal to plus 330 newton into distance from force.

01:40 Here we have 0 .79 plus 0 .79 meters.

01:46 This comes out to be equal to here we have 521 .4 newton meter...
