Question

Suppose a mass m is attached to two springs with spring constants k1 and k2 and lengths l1 and l2 in series. The mass moves horizontally. The motion equation of the mass is represented by: m(d^2x/dt^2) = -k2(x - xc - l2)....(ii) 1. (8 points) Find the equilibrium position of the mass m using (i) and (ii). 2. (6 points) Assume that k2 = k1 = k and l2 = l1 = l. Derive that m(d^2x/dt^2) = -kx from Problem 1. 3. (12 points) Solve the differential equation in Problem 2 and show that the mass executes simple harmonic motion about its equilibrium position. That is, show that the solution form is x(t) = Asin(wt + Ï†) + xE. 4. (5 points) Find the frequency w and period T. 5. (20 points) Let m = 1, k = 1, and l = 1. When the initial conditions x(0) = 2 and dx/dt(0) = 4 are given, find the equation of the energy, graph the energy curve and the corresponding phase plane. Check the stability of the equilibrium position based on the linearized stability analysis.

          Suppose a mass m is attached to two springs with spring constants k1 and k2 and lengths l1 and l2 in series. The mass moves horizontally.

The motion equation of the mass is represented by:

m(d^2x/dt^2) = -k2(x - xc - l2)....(ii)

1. (8 points) Find the equilibrium position of the mass m using (i) and (ii).
2. (6 points) Assume that k2 = k1 = k and l2 = l1 = l. Derive that m(d^2x/dt^2) = -kx from Problem 1.
3. (12 points) Solve the differential equation in Problem 2 and show that the mass executes simple harmonic motion about its equilibrium position. That is, show that the solution form is x(t) = Asin(wt + Ï†) + xE.
4. (5 points) Find the frequency w and period T.
5. (20 points) Let m = 1, k = 1, and l = 1. When the initial conditions x(0) = 2 and dx/dt(0) = 4 are given, find the equation of the energy, graph the energy curve and the corresponding phase plane. Check the stability of the equilibrium position based on the linearized stability analysis.

suppose a mass m is attached to two springs with spring constants ki and k2 and lengths li and l2 in series the mass moves horizontally x my m ky the motion equation of the mass is represent 57337
