The solid shaft AB rotates at 720 rpm and transmits 50 kW from the motor M to machine tools connected to gears E and F. Knowing that $\tau_{all}$ = 42 MPa and assuming that 20 kW is taken off at gear E and 30 kW is taken off at gear F, determine the smallest permissible diameter of shaft AB.
