Translate the following 32 bits into an instruction: 000000 01000 01001 10000 00000 100000 Question 1 options: A) add $8, $9, $16 B) and $16, $8, $9 C) add $16, $8, $9 D) and $8, $9, $16
Added by Tiffany W.
Step 1
The provided binary is: ``` 000000 01000 01001 10000 00000 100000 ``` This can be divided into the following fields for an R-type instruction: - **Opcode (6 bits)**: `000000` - **Source Register (rs) (5 bits)**: `01000` (which is register $8) - **Target Show more…
Show all steps
