Figure 15.18 showed how the ratio of the rate constants, $\frac{k_{2}}{k_{1}},$ for a reaction changes as a function of the energy of activation and the result was valid for a rise in temperature from 300 to $310 \mathrm{K}$. For values of $E_{\mathrm{a}}$ of 10,30,50,70,90,110,130 and $150 \mathrm{kJ} \mathrm{mol}^{-1},$ determine $\frac{k_{2}}{k_{1}}$ for a change in temperature from (a) 320 to $330 \mathrm{K}$ and (b) 420 to $430 \mathrm{K} .$ Plot $\frac{k_{2}}{k_{1}}$ as a function of $E_{\mathrm{a}} .$ What significant differences are there between your graphs and Figure $15.18 ?$ Comment critically on the statement that a rise in temperature of $10 \mathrm{K}$ leads to an approximate doubling of the rate of reaction.
