A 1.60-L gasoline engine with a compression ratio of 6.20...

A $1.60-\mathrm{L}$ gasoline engine with a compression ratio of 6.20 has a useful power output of 102 $\mathrm{hp}$ . Assuming the engine operates in an idealized Otto cycle, find the energy taken in and the energy exhausted each second. Assume the fuel-air mixture behaves like an ideal gas with $\gamma=1.40 .$

Key Concepts

Thermodynamic Energy Transfer in Engine Cycles

Analyzing the energy taken in (via fuel combustion and subsequent heat addition) versus the energy exhausted (through heat rejection) is key to understanding the efficiency of engine cycles. In thermodynamic analyses of engines like those following the Otto cycle, the net work output is determined by the difference between the energy added during combustion and the energy lost during the exhaust process, highlighting the importance of energy transfer and balance.

Power Output and Energy Conversion

Power output, often measured in horsepower, quantifies the rate at which an engine performs work. In the analysis of engine cycles, converting power into energy per unit time (energy transferred per second) is essential to relate mechanical energy outputs to the thermodynamic processes happening within the engine. This concept connects the macroscopic performance metrics with the microscopic energy transformations.

Otto Cycle

The Otto cycle is an idealized thermodynamic cycle that represents how traditional spark ignition internal combustion engines operate. It consists of adiabatic compression, constant volume heat addition, adiabatic expansion, and constant volume heat rejection processes. Understanding the Otto cycle is crucial when analyzing engine performance, efficiency, and thermodynamic energy transfers in combustion engines.

Compression Ratio

The compression ratio is defined as the ratio of the total volume of the combustion chamber when the piston is at the bottom dead center to the volume when it is at the top dead center. This parameter is a key factor in engine efficiency, influencing the maximum pressure achieved during the compression stroke and thus the work output of the engine, under idealized conditions like those assumed in the Otto cycle.

Ideal Gas Behavior

Assuming the fuel-air mixture behaves like an ideal gas simplifies the analysis of combustion engines by allowing the use of the ideal gas law to describe the state variables of the gas. This assumption, along with the definition of the specific heat ratio (gamma), aids in modeling the adiabatic compression and expansion processes within the Otto cycle.
