A 480 V rms line feeds two balanced threephase loads. If...

A $480 \mathrm{~V}$ rms line feeds two balanced threephase loads. If the two loads are rated as follows:
Load $1: 5 \mathrm{kVA}$ at $0.8 \mathrm{PF}$ lagging
Load 2: $10 \mathrm{kVA}$ at 0.9 PF lagging
determine the magnitude of the line current from the $480 \mathrm{~V}$ rms source.

Key Concepts

Line Current Calculation Formula

The line current in a three-phase system can be determined using the relationship between the total apparent power, the line-to-line voltage, and the ?3 factor. The formula, often expressed as I_line = S_total / (?3 * V_line), allows for the calculation of the current based on the combined kVA ratings of the loads. This formula is fundamental in electrical engineering for proper system design, ensuring that supply lines and protective devices are sized appropriately.

Load Combination for Multiple Loads

When multiple loads are connected to the same power source, their individual apparent powers must be combined to determine the total demand on the system. This usually involves a vector sum if the loads have different power factors or phase angles, or a direct arithmetic sum if they are aligned. Correctly combining these loads is crucial to accurately determine the overall line current and ensure the power source is adequately rated.

Three-Phase Power Systems

In three-phase power systems, the total power is related to the line-to-line voltage, the line current, and the square root of three. The formulas used in these systems account for the phase relationships between the three sinusoidal voltages, making it important to include the factor of ?3 when computing power or current. This concept is critical for understanding how balanced three-phase loads operate and interact with a given line voltage.

Apparent Power and Power Factor

Apparent power (measured in kVA) represents the combination of real and reactive power in an AC circuit, and it is connected to the power factor, which is the cosine of the phase angle between voltage and current. The power factor indicates how effectively the electrical power is being used. A lagging power factor signifies the presence of reactive power, which does not perform useful work but affects overall current levels. Understanding these relationships is essential for calculating line currents and for designing systems that efficiently use electrical power.
