David V. Kerns, Jr., J. David Irwin

Chapter 5

Steady-State Power Analysis - all with Video Answers

Educators


Chapter Questions

02:26

Problem 1

In the circuit in Figure P5.1, $v_1(t)=12 \cos$ $\left(377 t-40^{\circ}\right) \mathrm{V}$. Determine the equations for the current and instantaneous power as a function of time.
Figure P5.1 can't copy

Khoobchandra Agrawal
Khoobchandra Agrawal
Numerade Educator
02:41

Problem 2

In the network in Figure P5.2, $v_1(t)=24 \cos$ $\left(377 t+20^{\circ}\right) \mathrm{V}$. Find the equations for the current and instantaneous power as a function of time.
Figure P5.2 can't copy

Narayan Hari
Narayan Hari
Numerade Educator

Problem 3

Determine the total average power absorbed and supplied in the network in Figure P5.3.
Figure P5.3 can't copy

Check back soon!

Problem 4

Determine the total average power absorbed and supplied in the network in Figure P5.4.
Figure P5.4 can't copy

Check back soon!

Problem 5

Determine the average power absorbed in the $4 \Omega$ resistor in the circuit in Figure P5.5.
Figure P5.5 can't copy

Check back soon!

Problem 6

Determine the average power absorbed in the $6 \Omega$ resistor in the network in Figure P5.6.
Figure P5.6 can't copy

Check back soon!
01:17

Problem 7

Find the total average power absorbed and supplied in the circuit in Figure P5.7.
Figure P5.7 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
04:33

Problem 8

Find the total average power absorbed and supplied in the network in Figure P5.8.
Figure P5.8 can't copy

Thomas Thompson
Thomas Thompson
Numerade Educator
01:17

Problem 9

Find the total average power absorbed and supplied in the circuit in Figure P5.9.
Figure P5.9 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
05:16

Problem 10

Show that the conservation of power holds for the network shown in Figure P5.10.
Figure P5.10 can't copy

Thomas Thompson
Thomas Thompson
Numerade Educator

Problem 11

Given the network in Figure P5.11, determine the average power absorbed or supplied by each element.
Figure P5.11 can't copy

Check back soon!

Problem 12

Find the total average power absorbed and supplied in the circuit in Figure P5.12.
Figure P5.12 can't copy

Check back soon!
03:46

Problem 13

Determine the average power absorbed and supplied by each element in the network in Figure P5.13.
Figure P5.13 can't copy

Thomas Thompson
Thomas Thompson
Numerade Educator
01:10

Problem 14

Determine the rms value of the waveform in Figure P5.14
Figure P5.14 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
01:10

Problem 15

Calculate the rms value of the waveform shown in Figure P5.15.
Figure P5.15 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
01:10

Problem 16

Determine the rms value of the waveform shown in Figure P5.16.
Figure P5.16 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
01:10

Problem 17

Compute the rms value of the voltage waveform shown in Figure P5.17.
Figure P5.17 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
02:21

Problem 18

The current waveform in Figure P5.18 exists in a $10 \Omega$ resistor. Determine the average power delivered to the resistor.
Figure P5.18 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
01:43

Problem 19

The current in a $4 \Omega$ resistor is given by the waveform in Figure P5.19. Find the average power absorbed by the resistor.
Figure P5.19 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
02:21

Problem 20

The current in a $2 \Omega$ resistor is given by the waveform shown in Figure P5.20. Find the average power absorbed by the resistor.
Figure P5.20 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
01:43

Problem 21

The voltage across a $4 \Omega$ resistor is given by the waveform shown in Figure P5.21. Find the average power absorbed by the resistor.
Figure P5.21 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
01:01

Problem 22

The power consumed by an industrial load is $120 \mathrm{~kW}$ at $0.70 \mathrm{PF}$ lagging from a $480 \mathrm{~V}$ rms line. If the transmission line resistance between the generator and the load is $0.14 \Omega$, find the power that must be supplied by the power company.

Narayan Hari
Narayan Hari
Numerade Educator
01:01

Problem 23

An industrial load consumes $100 \mathrm{~kW}$ at $0.8 \mathrm{PF}$ lagging. The line voltage is $480 \mathrm{~V} \mathrm{rms}$. If the line resistance between the generator and load is $0.1 \Omega$, find the transmission line losses.

Narayan Hari
Narayan Hari
Numerade Educator
01:01

Problem 24

If the power factor in problem 5.23 is changed to 0.92 lagging, determine the effect on the line losses.

Narayan Hari
Narayan Hari
Numerade Educator
01:19

Problem 25

A load operates at $20 \mathrm{~kW}, 0.8$ PF lagging. The load voltage is $220 \angle 0^{\circ} \mathrm{V}$ rms at $60 \mathrm{~Hz}$. The impedance of the line is $0.09+j 0.3 \Omega$. Determine the voltage and power factor at the input to the line.

Narayan Hari
Narayan Hari
Numerade Educator
01:17

Problem 26

A particular load has a PF of 0.8 lagging. The power delivered to the load is $40 \mathrm{~kW}$ from a $220 \mathrm{~V} \mathrm{rms} 60 \mathrm{~Hz}$ line. If the transmission line resistance is $0.085 \Omega$, determine the real power that must be generated at the supply.

Narayan Hari
Narayan Hari
Numerade Educator
01:01

Problem 27

The line voltage at an industrial load is $220 \mathrm{~V}$ rms The load consumes $50 \mathrm{~kW}$ at $0.75 \mathrm{PF}$ lagging. The line resistance from the power company's transformer to the load is $0.1 \Omega$. Determine the savings in line losses if the PF is somehow changed to 0.92 lagging.

Narayan Hari
Narayan Hari
Numerade Educator
03:53

Problem 28

Calculate the voltage $\mathbf{V}_s$ that must be supplied to obtain $2 \mathrm{~kW}, 240 \angle 0^{\circ} \mathrm{V}$ rms, and a power factor of 0.8 leading at the load $\mathbf{Z}_L$ in the network in Figure P5.28.
Figure P5.28 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
01:33

Problem 29

An industrial plant at the end of a transmission line consumes $144 \mathrm{~kW}$ at 0.88 PF lagging. The line voltage at the plant is $480 \angle 0^{\circ} \mathrm{V}$ rms. The resistance of the transmission line is $0.13 \Omega$. Determine the voltage and power factor at the input of the transmission line.

Narayan Hari
Narayan Hari
Numerade Educator
03:02

Problem 30

A plant, representing the load on a transmission line, consumes $110 \mathrm{~kW}$ at 0.88 PF lagging. The load line voltage is $480 \angle 0^{\circ} \mathrm{V}$ rms. If the transmission line resistance is $0.15 \Omega$, determine the complex power at both ends of the line.

Narayan Hari
Narayan Hari
Numerade Educator
01:33

Problem 31

An industrial plant consumes $160 \mathrm{~kW}$ at 0.9 PF lagging. The line voltage at the plant is $480 \angle 0^{\circ} \mathrm{V}$ rms. The transmission line feeding the plant is 2 miles long. If the impedance of the line is $0.1+j 0.2 \Omega$, find the power factor at the sending end of the line.

Narayan Hari
Narayan Hari
Numerade Educator
02:35

Problem 32

A small plant has a bank of induction motons that consume $64 \mathrm{~kW}$ at a PF of 0.68 lagging. The $60 \mathrm{~Hz}$ line voltage across the motors is $220 \angle 0^{\circ} \mathrm{V}$ rms. The local power company has told the plant to raise the PF to 0.92 lagging. What value of capacitance is required?

Narayan Hari
Narayan Hari
Numerade Educator
01:26

Problem 33

What value of capacitance, placed in parallel with the load in problem 5.26 , will raise the 7 to 0.9 lagging?

Kratika Bhadauria
Kratika Bhadauria
Numerade Educator
02:23

Problem 34

An industrial plant consumes $75 \mathrm{~kW}$ at $0.84 \mathrm{Pf}$ lagging when connected to a $220 \angle 0^{\circ} \mathrm{V}$ rm $60 \mathrm{~Hz}$ line. Determine the value of the capacitance, which, when placed in parallel with the load, will raise the power factor to $0<$ lagging.

Narayan Hari
Narayan Hari
Numerade Educator
02:16

Problem 35

An industrial load is connected to a $60 \mathrm{~Hz}$ line and the load voltage is $480 \angle 0^{\circ} \mathrm{V}$ rms. The load consumes $120 \mathrm{~kW}$ at $0.77 \mathrm{PF}$ lagging. $\mathrm{Sz}$ lect the capacitor value needed to raise th power factor to 0.9 lagging.

Narayan Hari
Narayan Hari
Numerade Educator
02:35

Problem 36

An industrial plant draws $100 \mathrm{~kW}$ at $0.7 \mathrm{Fr}$ lagging from a $480 \angle 0^{\circ} \mathrm{V} \mathrm{rms}, 60 \mathrm{~Hz}$ line. a $500 \mu \mathrm{F}$ capacitor bank is placed in paral with the load, what is the new power factor

Narayan Hari
Narayan Hari
Numerade Educator
03:32

Problem 37

An abc-sequence three-phase voltage source connected in a balanced wye has a phase voltage of $\mathbf{V}_{a n}=120 \angle-45^{\circ} \mathrm{V}$ rms. Determitu the line voltages of the source.

Narayan Hari
Narayan Hari
Numerade Educator

Problem 38

An abc-sequence three-phase voltage sourconnected in a balanced wye has a line vor age of $\mathbf{V}_{a b}=208 \angle 175^{\circ} \mathrm{V}$ rms. Find phase voltages of the source.

Check back soon!

Problem 39

A three-phase, abc-sequence, balanced wys connected source is connected to a balanoted wye-connected load. The phase voltage of tit source is $120 \mathrm{~V} \mathrm{rms}$, the load impedance : $16+j 8 \Omega$, and the line impedance is negligs ble. Determine the line currents.

Check back soon!
05:19

Problem 40

If the line impedance in problem 5.39 is $0.8+j 0.6 \Omega$, determine the line currents and the load voltages.

Ramesh Singh
Ramesh Singh
Numerade Educator

Problem 41

An abc-sequence balanced three-phase wyeconnected source with a phase voltage of 100 $\mathrm{V}$ rms supplies power to a balanced wye-connected load. The per-phase load impedance is $40+j 10 \Omega$. Determine the line currents in the circuit if $\angle \mathbf{V}_{a n}=0^{\circ}$.

Check back soon!

Problem 42

An abc-sequence balanced three-phase wyeconnected source supplies power to a balanced wye-connected load. The line impedance per phase is $1+j 0 \Omega$, and the load impedance per phase is $20+j 20 \Omega$. If the source line voltage $\mathbf{V}_{a b}$ is $100 \angle 0^{\circ} \mathrm{V}$ rms, find the line currents.

Check back soon!

Problem 43

An abc-sequence balanced wye-connected source supplies a balanced wye-connected load. If the line voltage at the source is $\mathbf{V}_{a b}=240 \angle 0^{\circ} \mathrm{V}$ rms, the load impedance is $18+j 12 \Omega$, and the line impedance is $1.2+j 1 \Omega$, determine the line currents and the load voltages.

Check back soon!

Problem 44

An abc-sequence balanced wye-connected source supplies a balanced wye-connected load. If the line impedance is $1+j 1 \Omega$, the load impedance is $12+j 8 \Omega$, and the load voltage is $\mathbf{V}_{A N}=109.46 \angle 18.99^{\circ} \mathrm{V} \mathrm{rms}$, determine the source voltages.

Check back soon!
02:14

Problem 45

In a balanced three-phase wye-delta system, the line current is $\mathbf{I}_{a A}=8 \angle 13.13^{\circ} \mathrm{A} \mathrm{rms}$. If the impedance per phase of the delta load is $36+j 27 \Omega$, find the source voltage if the line impedance can be ignored.

Narayan Hari
Narayan Hari
Numerade Educator

Problem 46

In a balanced three-phase wye-delta system, the phase voltage of the source is $\mathbf{V}_{a n}=120 \angle 10^{\circ} \mathrm{V}$ rms, and the load impedance per phase in the $\Delta$ is $24+j 18 \Omega$. If the line impedance is negligible, determine the line currents in the system.

Check back soon!
02:23

Problem 47

In a balanced three-phase wye-delta system, the line voltage is $\mathbf{V}_{a b}=120 \sqrt{3} \angle 70^{\circ} \mathrm{V} \mathrm{rms}$ and the line current is $\mathbf{I}_{a A}=24 \angle 3.13^{\circ}$ A rms. If the line impedance is negligible, find the impedance per phase of the delta load.

Narayan Hari
Narayan Hari
Numerade Educator

Problem 48

In a balanced three-phase wye-delta system, the source has an abc phase sequence. The load impedance is $12+j 8 \Omega$. If the phase voltage at the load is $\mathbf{V}_{A B}=260 \angle 45^{\circ} \mathrm{V}$ rms, find the line currents and the phase voltages of the source.

Check back soon!

Problem 49

In a balanced three-phase wye-delta system, the impedance per phase of the load is $21+j 9 \Omega$ and the source voltage is $\mathbf{V}_{a b}=120 \sqrt{3} \angle 60^{\circ} \mathrm{V}$ rms. If the line impedance is $1+j 1 \Omega$, determine the line currents.

Check back soon!
02:23

Problem 50

A balanced three-phase system has a load that consists of a balanced wye in parallel with a balanced delta. The impedance per phase of the wye is $10+j 8 \Omega$ and the impedance per phase of the delta is $24+j 12 \Omega$. Determine both the equivalent wye load and the equivalent delta load.

Narayan Hari
Narayan Hari
Numerade Educator
02:23

Problem 51

A three-phase load impedance consists of a balanced wye in parallel with a balanced delta, as shown in Figure P5.51. Determine the equivalent delta load.
Figure P5.51 can't copy

Narayan Hari
Narayan Hari
Numerade Educator
02:14

Problem 52

An abc-phase-sequence three-phase voltage source connected in a balanced wye supplies power to a balanced delta-connected load. The load current $\mathbf{I}_{A B}=4 \angle 20^{\circ} \mathrm{A} \mathrm{rms}$. Determine the line currents.

Narayan Hari
Narayan Hari
Numerade Educator
02:14

Problem 53

An abc-sequence balanced three-phase wye-connected source supplies power to a balanced delta-connected load. The load impedance per phase is $12+j 8 \Omega$. If the current $\mathbf{I}_{A B}$ in one phase of the delta is $14.42 \angle 86.31^{\circ}$ A rms, determine the line currents and phase voltages at the source.

Narayan Hari
Narayan Hari
Numerade Educator
04:10

Problem 54

Find $I_{a y}$ in the circuit shown in Figure P5.54.
Figure P5.54 can't copy

Khoobchandra Agrawal
Khoobchandra Agrawal
Numerade Educator

Problem 55

Consider the network shown in Figure P5.55. Compute the magnitude of the line voltages at the load and the magnitude of the phase currents in the delta-connected source.
Figure P5.55 can't copy

Check back soon!

Problem 56

A balanced three-phase delta-delta system has the following parameters: $\mathbf{V}_{a b}=207.84$ $\angle-20^{\circ} \mathrm{V}$ rms, $\mathbf{Z}_{\text {Line }}=1+j 1.2 \Omega$, and $\mathbf{Z}_{\text {Load }}$ $=18+j 12 \Omega$. Find the line currents.

Check back soon!
02:27

Problem 57

Two small industries located side-by-side are fed from a three-phase balanced $60 \mathrm{~Hz}$ source with a line voltage of $208 \mathrm{~V}$ rms. Load #1 consumes $24 \mathrm{~kW}$ at $0.75 \mathrm{PF}$ lagging and load #2 consumes $16 \mathrm{~kW}$ at $0.88 \mathrm{PF}$ lagging. Determine the current in the line that serves both loads.

Narayan Hari
Narayan Hari
Numerade Educator
02:23

Problem 58

A $480 \mathrm{~V}$ rms line feeds two balanced threephase loads. If the two loads are rated as follows:
Load $1: 5 \mathrm{kVA}$ at $0.8 \mathrm{PF}$ lagging
Load 2: $10 \mathrm{kVA}$ at 0.9 PF lagging
determine the magnitude of the line current from the $480 \mathrm{~V}$ rms source.

Narayan Hari
Narayan Hari
Numerade Educator
02:23

Problem 59

A balanced three-phase source serves the following loads:
Load $1: 48 \mathrm{kVA}$ at $0.9 \mathrm{PF}$ lagging
Load 2: $24 \mathrm{kVA}$ at $0.75 \mathrm{PF}$ lagging
The line voltage at the load is $208 \mathrm{~V}$ rms at 60 $\mathrm{Hz}$. Determine the line currents and the combined power factor at the load.

Narayan Hari
Narayan Hari
Numerade Educator
04:00

Problem 60

Three industrial loads are supplied by a balanced three-phase source. The line voltage at the loads is $208 \mathrm{~V}$ rms at $60 \mathrm{~Hz}$. The characteristics of the loads are
Load $1: 20 \mathrm{~kW}$ at $0.8 \mathrm{PF}$ lagging
Load 2: $26 \mathrm{~kW}$ at $0.85 \mathrm{PF}$ leading
Load 3: $18 \mathrm{~kW}$ at 0.9 PF lagging
determine the total complex power and power factor of the load.

Narayan Hari
Narayan Hari
Numerade Educator
03:12

Problem 61

A balanced three-phase wye-wye system has, two parallel loads. Load 1 is rated at $3000 \mathrm{VA}, 0.7 \mathrm{PF}$ lagging, and load 2 is rated at $2000 \mathrm{VA}, 0.75 \mathrm{PF}$ leading. If the line voltage is $208 \mathrm{~V}$ rms, find the magnitude of the line current.

Narayan Hari
Narayan Hari
Numerade Educator
02:05

Problem 62

Two industrial plants represent balanced three-phase loads. The plants receive their power from a balanced three-phase source with a line voltage of $4.6 \mathrm{kV}$ rms. Plant 1 is rated at $300 \mathrm{kVA}, 0.8 \mathrm{PF}$ lagging, and plant 2 is rated at $350 \mathrm{kVA}, 0.84 \mathrm{PF}$ lagging. Determine the power line current.

Narayan Hari
Narayan Hari
Numerade Educator
