A 500-μm-thick p-type Si wafer with a doping level of 1 ×10^15 cm^-3 has a certain region in wh

step 1 So in this question we have to find the electricity field and the average conductivity, the curr

A 500-μm-thick p-type Si wafer with a doping level of 1...

A $500-\mu$ m-thick p-type Si wafer with a doping level of $1 \times 10^{15} \mathrm{~cm}^{-3}$ has a certain region in which we do a constant source solid-solubility-limited P diffusion, resulting in a junction depth of $0.8 \mu \mathrm{m}$ and a surface concentration of $6 \times 10^{19} \mathrm{~cm}^{-3}$. We do sheet resistance measurements on the two parts of the wafer. What is the measured sheet resistance of the p-type part? If we have a sheet resistance of $90 \Omega /$ square in the n-type part, what is the average resistivity there?

Key Concepts

Junction Depth

Junction depth refers to the depth in a semiconductor where the dopant concentration falls to a level that defines the boundary between differently doped regions, such as between p-type and n-type areas. This parameter is crucial in determining the electrical characteristics of a semiconductor junction, influencing phenomena such as carrier diffusion and the overall behavior of devices such as diodes and transistors.

Diffusion Process

The diffusion process in semiconductors involves the introduction of dopant atoms into the substrate, where they migrate into the material driven by concentration gradients and thermal energy. Specifically, constant source solid-solubility-limited diffusion limits the maximum dopant concentration at the surface to the solubility limit, producing a predictable diffusion profile. This process is critical for forming junctions with well-defined depths and dopant concentrations.

Resistivity

Resistivity is an intrinsic property of a material that quantifies how strongly it opposes the flow of electric current. It is determined by factors such as the doping concentration and mobility of carriers in semiconductors. Resistivity is crucial for linking the electrical conductivity of a device to its microscopic properties, and when divided by the layer’s thickness, it can yield the sheet resistance for thin film structures.

Sheet Resistance

Sheet resistance is a measure of resistance of thin films that have uniform thickness, typically expressed in ohms per square (?/?). It represents how easily current flows through a layer regardless of its absolute size and is calculated by considering the resistivity of the material and the geometry (thickness) of the conductive layer. In semiconductor processing, measuring the sheet resistance provides vital clues to the dopant distribution and electrical performance of the device regions.

Semiconductor Doping

Semiconductor doping is the process of intentionally introducing impurities into an intrinsic semiconductor to modify its electrical properties. The addition of donors or acceptors creates free carriers (electrons or holes), which directly impact the resistivity and conductivity of the material. Understanding the level and type of doping is essential for predicting the behavior of semiconductor devices under various conditions.
