A benchtop experiment consists of a reservoir with a $500-m m-$ long horizontal tube of diameter $7.5 \mathrm{mm}$ attached to its base. The tube exits to a sink. A flow of water at $10^{\circ} \mathrm{C}$ is to be generated such that the Reynolds number is 10,000 What is the flow rate? If the entrance to the tube is squareedged, how deep should the reservoir be? If the entrance to the tube is well-rounded, how deep should the reservoir be?

A benchtop experiment consists of a reservoir with a $500-m m-$ long horizontal tube of diameter $7.5 \mathrm{mm}$ attached to its base. The tube exits to a sink. A flow of water at $10^{\circ} \mathrm{C}$ is
to be generated such that the Reynolds number is 10,000 What is the flow rate? If the entrance to the tube is squareedged, how deep should the reservoir be? If the entrance to the tube is well-rounded, how deep should the reservoir be?

Key Concepts

Reynolds Number

The Reynolds number is a dimensionless parameter in fluid mechanics that indicates whether a flow is laminar or turbulent. It is defined by the ratio of inertial forces to viscous forces and is calculated using fluid velocity, characteristic length (such as diameter), fluid density, and viscosity. Achieving a target Reynolds number allows engineers to design experiments that mimic the flow characteristics seen in real-life systems.

Volumetric Flow Rate

The volumetric flow rate quantifies the amount of fluid that passes through a given cross-sectional area per unit time. It is determined by the product of the fluid velocity and the cross-sectional area of the tube. Calculating the flow rate correctly is fundamental to assuring that the experimental conditions, like the Reynolds number, are met.

Entrance Effects

Entrance effects relate to the region at the start of a pipe where the flow transitions from an undisturbed, uniform velocity profile to a fully developed profile governed by viscous effects. The shape of the tube entrance, whether square-edged or well-rounded, influences the development length of the boundary layer. This, in turn, affects the stability and uniformity of the flow entering the tube.

Reservoir Depth for Flow Stabilization

Reservoir depth is important in bench-scale experiments to ensure that the flow entering the pipe is fully developed and has minimal disturbances from the entry. When the entrance to the tube is square-edged, additional depth is needed to allow the flow to stabilize, whereas a well-rounded entrance can promote faster development of the flow profile. Optimising reservoir depth helps maintain the desired flow characteristics and target Reynolds number in the experiment.
