A water system is used in a laboratory to study flow in a smooth pipe. The water is at $10^{\circ} \mathrm{C}$. To obtain a reasonable range, the maximum Reynolds number in the pipe must be $100,000 .$ The system is supplied from an overhead constant head tank. The pipe system consists of a square-edged entrance, two $45^{\circ}$ standard elbows, two $90^{\circ}$ standard clbows, and a fully open gate valve. The pipe diameter is $7.5 \mathrm{mm},$ and the total length of pipe is $1 \mathrm{m}$. Calculate the minimum height of the supply tank above the pipe system discharge to reach the desired Reynolds number. If a pressurized chamber is used instead of the reservoir, what will be the required pressure?

Key Concepts

Reynolds Number

The Reynolds number is a dimensionless quantity that characterizes the flow regime in a fluid system, indicating whether the flow is laminar or turbulent. It is defined as the ratio of inertial forces to viscous forces and is calculated using the fluid density, velocity, characteristic length (such as the pipe diameter), and dynamic viscosity. It is fundamental in determining the behavior of fluid flow within a pipe.

Darcy-Weisbach Equation

The Darcy-Weisbach equation is used to estimate the head loss due to friction along a pipe. It relates the frictional head loss to the length of the pipe, the flow velocity, the pipe diameter, and the friction factor. This equation is essential in analyzing fluid flow in pipes and determining the required energy (or pressure) to overcome frictional losses.

Friction Factor

The friction factor is a dimensionless quantity used in conjunction with the Darcy-Weisbach equation to quantify the resistance to flow in a pipe due to friction. It depends on the flow regime (laminar or turbulent) and the roughness of the pipe's interior surface. Accurate determination of the friction factor is critical for estimating head loss in pipeline systems.

Minor Losses

Minor losses refer to additional head losses that occur due to fittings, bends, valves, entrances, and other local disturbances in a piping system. These losses are typically estimated using loss coefficients or equivalent lengths and must be added to the frictional losses calculated by the Darcy-Weisbach equation to accurately assess the total energy required to drive the flow.

Hydrostatic Pressure and Head Conversion

Hydrostatic pressure describes the pressure exerted by a fluid at rest due to the force of gravity acting on a column of fluid. The relationship between pressure and head is given by the equation p = ?gh, where ? is the fluid density, g is gravitational acceleration, and h is the height of the fluid column. This conversion is crucial when designing systems that use an overhead reservoir or a pressurized chamber to supply the necessary energy or elevation head to achieve a desired flow condition.
