A couple 𝐌 will be applied to a beam of rectangular cross...

A couple $\mathbf{M}$ will be applied to a beam of rectangular cross section that is to be sawed from a log of circular cross section. Determine the ratio $d / b$ for which $(a)$ the maximum stress $\sigma_{m}$ will be as small as possible, (b) the radius of curvature of the beam will be maximum.

Key Concepts

Geometric Optimization Under Constraints

This concept involves selecting the beam’s cross-sectional dimensions to achieve desired mechanical performance while respecting external limitations, such as material waste or shape constraints (e.g., being cut from a circular log). It requires establishing the relationships between stress, stiffness, and cross-sectional geometry, then determining the optimal ratios that balance these factors.

Radius of Curvature

The radius of curvature in a bending beam is linked to the flexural rigidity and the applied moment. A larger radius corresponds to a gentler curve, meaning the beam is bending less sharply, which is often a desirable property for durability and load distribution. It is influenced by the beam's geometry and material properties, making it a key parameter in design optimization.

Moment of Inertia

The moment of inertia is a geometric property of the beam's cross-section that quantifies its resistance to bending. For different shapes, especially for a rectangle, its value affects both the maximal bending stress and the beam's deflection. The distribution of material relative to the neutral axis is key in determining I, making it central to assessing and optimizing the performance of structural members under bending loads.

Section Modulus

The section modulus, defined as the moment of inertia divided by the distance from the neutral axis to the extreme fiber, is a critical factor in determining a beam’s bending strength. It indicates the efficiency of a given cross-sectional shape in resisting bending stresses. Optimizing the section modulus can lead to designs that minimize maximum stress for a given applied moment.

Bending Stress

Bending stress is the internal stress induced in a beam when a moment is applied. It can be expressed by the formula ? = M·c/I, where M is the applied moment, c is the distance from the neutral axis to the outermost fiber, and I is the moment of inertia of the beam’s cross-sectional shape. Understanding how to calculate and minimize this stress is essential in structural design.
