A dipole consists of two equal and opposite point charges (±q) separated by a distance d . (a) W

step 1 So here we have plus d over 2 and minus t over 2 and over here we are supposed to write what is

A dipole consists of two equal and opposite point charges...

A dipole consists of two equal and opposite point charges $(\pm q)$ separated by a distance $d .$ (a) Write an expression for the electric field at a point $(0, y)$ on the dipole axis. Specify the direction of the field in all four regions: $y>\frac{1}{2} d, 0<y<\frac{1}{2} d,-\frac{1}{2} d<y<0,$ and $y<-\frac{1}{2} d .$ (b) At distant points $(|y| \gg d),$ write a simpler, approximate expression for the field. To what power of $y$ is the field proportional? Does this conflict with Coulomb's law? [Hint: Use the binomial approximation $\left.(1 \pm x)^{n} \approx 1 \pm n x \text { for } x \ll 1 .\right]$

A dipole consists of two equal and opposite point charges $(\pm q)$ separated by a distance $d .$ (a) Write an expression for the electric field at a point $(0, y)$ on the dipole axis. Specify the direction of the field in all four regions: $y>\frac{1}{2} d, 0<y<\frac{1}{2} d,-\frac{1}{2} d<y<0,$ and $y<-\frac{1}{2} d .$ (b) At distant
points $(|y| \gg d),$ write a simpler, approximate expression for the field. To what power of $y$ is the field proportional? Does this conflict with Coulomb's law? [Hint: Use the binomial approximation $\left.(1 \pm x)^{n} \approx 1 \pm n x \text { for } x \ll 1 .\right]$

Key Concepts

Electric Dipole

An electric dipole is a system consisting of two equal and opposite charges separated by a finite distance. It is characterized by a dipole moment, which is the product of the charge and the separation distance, and it creates a unique electric field that differs in both magnitude and direction from that produced by a single point charge.

Superposition Principle

The superposition principle in electrostatics states that the total electric field created by multiple charges is the vector sum of the electric fields due to each individual charge. This concept is crucial in calculating the field due to a dipole by adding the contributions from both the positive and negative charges.

Coulomb's Law

Coulomb's law provides the fundamental relation for the electric field generated by a point charge, indicating that the field strength is proportional to the charge and inversely proportional to the square of the distance from the charge. This principle forms the basis for calculating the individual fields from each charge in a dipole arrangement.

Binomial Approximation

The binomial approximation is a mathematical technique used to simplify expressions that involve terms with small parameters relative to a larger one. In the context of dipole fields at large distances, it allows the simplification of the electric field expressions by approximating terms where the separation distance is much smaller than the distance to the field point.

Dipole Field Asymptotics

At distances much larger than the separation between the dipole charges, the electric field of a dipole decays proportionally to 1/r^3 instead of 1/r^2, as seen in the field from a single point charge. This faster decay is a direct consequence of the dipole's configuration and does not conflict with Coulomb's law, since the dipole has a net charge of zero.
