A liquid stream containing 50.0 mole $\%$ benzene and the balance toluene at $25^{\circ} \mathrm{C}$ is fed to a continuous single-stage evaporator at a rate of $1320 \mathrm{mol} / \mathrm{s}$. The liquid and vapor streams leaving the evaporator are both at $95.0^{\circ} \mathrm{C}$. The liquid contains 42.5 mole $\%$ benzene and the vapor contains 73.5 mole\% benzene. (a) Calculate the heating requirement for this process in $\mathrm{kW}$. (b) Using Raoult's law (Section 6.4b) to describe the equilibrium between the vapor and liquid outlet streams, determine whether or not the given benzene analyses are consistent with each other. If they are, calculate the pressure (torr) at which the evaporator must be operating; if they are not, give several possible explanations for the inconsistency.

A liquid stream containing 50.0 mole $\%$ benzene and the balance toluene at $25^{\circ} \mathrm{C}$ is fed to a continuous single-stage evaporator at a rate of $1320 \mathrm{mol} / \mathrm{s}$. The liquid and vapor streams leaving the evaporator are both at $95.0^{\circ} \mathrm{C}$. The liquid contains 42.5 mole $\%$ benzene and the vapor contains 73.5 mole\% benzene.
(a) Calculate the heating requirement for this process in $\mathrm{kW}$.
(b) Using Raoult's law (Section 6.4b) to describe the equilibrium between the vapor and liquid outlet streams, determine whether or not the given benzene analyses are consistent with each other. If they are, calculate the pressure (torr) at which the evaporator must be operating; if they are not, give several possible explanations for the inconsistency.

Key Concepts

Raoult’s Law

Raoult’s law is an ideal solution thermodynamic principle used to predict the partial vapor pressures of components in a liquid mixture based on their mole fractions and pure component vapor pressures. It is fundamental in the analysis of vapor–liquid equilibrium and is used to verify whether the component compositions in the vapor and liquid phases are consistent with equilibrium at a given pressure and temperature.

Vapor–Liquid Equilibrium

Vapor–liquid equilibrium (VLE) refers to the state where the vapor phase and the liquid phase are in equilibrium with each other, meaning the rates of evaporation and condensation are equal. Understanding VLE is crucial in designing separation processes like evaporation, as it ties together the composition of each phase with temperature and pressure conditions, and it helps in determining operating parameters such as pressure.

Energy Balance

Energy balance involves accounting for all energy inputs and outputs in a process. In the context of a continuous evaporator, this concept is applied to compute the heating requirement needed to raise the temperature of the liquid to vaporize part of it. It encompasses the heat supplied, the enthalpy changes associated with the temperature increase, and the phase change from liquid to vapor.

Mass Balance

Mass balance is the principle that mass is conserved in a process unit. In separation processes like evaporation, it involves accounting for the total amounts and compositions of components in the inlet and the outlet streams. This allows engineers to determine individual stream flow rates and composition changes across the process unit, which is essential when designing or analyzing separations.
