A NOT gate is modeled using an inverter similar to that shown in Figure P11.20. For $V_{\text {in }}=V_{D D}=5 \mathrm{~V}$ and $V_{\text {out }}=0.2 \mathrm{~V}$, determine the load resistance, $R_L$, and the $n$-channel ON source-to-drain resistance $\left(r_{o n}\right)$ if the power dissipated in the load resistance during $\mathrm{ON}$ state is $0.48 \mathrm{~mW}$.

Key Concepts

MOSFET On-Resistance (r_on)

The MOSFET on-resistance, typically denoted as r_on, characterizes the effective resistance between the source and drain when the transistor is in its conduction (ON) state. This resistance is crucial in determining the voltage drop across the device during operation, affecting both the performance and power dissipation of the circuit.

Ohm's Law and Power Dissipation in Resistive Networks

Ohm's Law, which relates voltage, current, and resistance, underpins the analysis of resistive networks in electronic circuits. Understanding power dissipation—calculated as the product of the square of the current and the resistance—is essential for designing circuits that manage heat effectively and operate efficiently under load conditions.

Digital Logic Inverter

A digital logic inverter, or NOT gate, is a fundamental component in digital electronics that produces an output which is the logical complement of its input. This concept is central to digital circuit design and forms the basis for more complex logic architectures by enabling binary state manipulation.

Load Resistance in Transistor Circuits

Load resistance in transistor circuits is a key element used to develop a voltage divider with the transistor's inherent on-resistance. It helps to set the output voltage levels in digital circuits, ensuring that the device operates within the desired logic thresholds, while also influencing the current flow and power consumption of the circuit.
