A PC's serial port transfers data in byte-size units. Typically, several additional bits are exchanged between transmitter and receiver to coordinate the transfer. This is called handshaking. A part of handshaking is a short bit sequence called the stop bits, which immediately follow the data byte. In a particular serial communication protocol the stop bits are the four-bit sequence 1111. This sequence does not occur elsewhere in the transmission. Using $\mathrm{J}-\mathrm{K}$ flip-flops, design a detection circuit that will recognize the stop bits sequence. The output, STOP, is high when the sequence is detected.

Key Concepts

Sequential Circuit Design

Sequential circuit design is a methodology in digital electronics where the output depends not only on the current inputs but also on the historical sequence of past inputs. This design paradigm typically utilizes storage elements like flip-flops to maintain state information over time.

JK Flip-Flops

JK flip-flops are a type of bistable multivibrator used in digital circuits for storage and sequential logic operations. They offer the ability to set, reset, or toggle their output based on the inputs and clock signals, making them versatile building blocks in designing state machines and timing circuits.

Finite State Machines

Finite state machines (FSMs) are abstract models used to design both sequential logic circuits and software algorithms. An FSM consists of a finite number of states, transitions between those states based on inputs, and defined outputs, which can be used for tasks like bit-pattern detection in communication systems.

Handshaking

Handshaking refers to the protocols and additional signals exchanged between two devices to establish, manage, and terminate a communication link. It ensures that data transfer occurs reliably by coordinating timing, error checking, and synchronization actions between transmitter and receiver.

Serial Communication

Serial communication is the process of sending data one bit at a time over a communication channel. This method is widely used in computer systems to transfer information between devices with relatively low hardware complexity, and it is essential in scenarios where long distances or limited wiring is required.

Stop Bits

Stop bits are specific bit sequences sent at the end of a data byte in serial communication to signal the end of the transmission for that byte. They provide the receiver with a moment to process the received data and prepare for the next byte, contributing to the synchronization of the data flow.
