A ray of light passes from air through dense flint glass and...

A ray of light passes from air through dense flint glass and then back into air. The angle of incidence on the first glass surface is $60.0^{\circ} .$ The thickness of the glass is $5.00 \mathrm{~mm}$; its front and back surfaces are parallel. How far is the ray displaced as a result of traveling through the glass?

Key Concepts

Snell's Law

Snell's Law describes how light bends when it passes from one medium to another with a different refractive index. It is expressed as n? sin(??) = n? sin(??), linking the angle of incidence and the angle of refraction with the refractive indices of the two media. This relationship is fundamental in predicting how a light ray changes direction at an interface, which is essential for solving problems in geometric optics.

Refraction through a Plane-Parallel Slab

When light passes through a plane-parallel slab, such as a flat piece of glass with parallel faces, it undergoes two refractions: one upon entering and one when exiting the slab. Although the direction of the light ray is eventually restored to its original orientation, the ray experiences a lateral displacement. Understanding the effect of the parallel interfaces is crucial in analyzing and calculating the overall path of the light within the slab.

Lateral Displacement

Lateral displacement refers to the sideways shift of a light beam after traversing a medium, such as a glass slab, compared to its original propagation path. This displacement occurs because, while the ray emerges parallel to its incident direction, the two refractions at the slab surfaces result in a spatial offset. Calculating this distance involves geometric relationships between the incident angle, the refracted angle, and the thickness of the slab.
