A short column is made by nailing four $1 \times 4$ -in. planks to a $4 \times 4$ -in. timber. Using an allowable stress of 600 psi, determine the largest compressive load $\mathbf{P}$ that can be applied at the center of the top section of the timber column as shown if $(a)$ the column is as described, (b) plank 1 is removed, $(c)$ planks 1 and 2 are removed, (d) planks 1 $2,$ and 3 are removed $(e)$ all planks are removed.

A short column is made by nailing four $1 \times 4$ -in. planks to a $4 \times 4$ -in. timber. Using an allowable stress of 600 psi, determine the largest compressive load $\mathbf{P}$ that can be applied at the center of the top section of the timber column as shown if $(a)$ the column is as described,
(b) plank 1 is removed,
$(c)$ planks 1 and 2 are removed,
(d) planks 1 $2,$ and 3 are removed
$(e)$ all planks are removed.

Key Concepts

Cross-sectional Properties and Load Capacity

Understanding the cross-sectional properties, such as area and moment of inertia, is essential when calculating the load capacity of a column. These properties dictate how stresses are distributed within the section, and any modification—such as adding or removing reinforcing elements—affects the overall strength and stability of the column under compressive loads.

Axial Compression Analysis

Axial compression analysis deals with determining the stresses induced by loads acting along the centroidal axis of a structural member. In column design, this analysis is crucial in assessing whether the compressive forces, when applied to a component's cross-sectional area, remain within safe limits, and in predicting potential failure modes such as material yielding or local crushing.

Effect of Reinforcement Configuration

The configuration and presence of additional reinforcing elements influence the load distribution and effective cross-sectional area of a composite column. Changes in the reinforcement, such as the removal of certain planks, alter the composite action and directly impact the column’s compressive strength by modifying both the stress distribution and capacity to carry the applied load.

Composite Structural Members

This concept involves combining different materials or elements to form a single structural unit that acts together to resist loads. In the context of columns, composite action enables elements with distinct material properties and cross-sectional dimensions to work in unison through connections, improving overall load carrying capacity and performance under compression.

Allowable Stress Design Method

Allowable stress design is a traditional engineering approach where materials are used within defined stress limits to ensure structural safety. The method involves comparing applied stresses with predetermined allowable stresses (or safety factors) to ensure that no member exceeds its inherent material capacity, thus preventing failure under the applied loads.

Transcript

00:03 Here first so the design of this section is fixed based on the allowable shear force in each nail so let us first find the sheer flow allowed by the nails at the joint interference sorry interface using the formula f is equal to queue as f is the shear force in each nail q is the shear flow as is the spacing between the nails so we have a shear forces 17 q multiplied by this spacing between the nails is 2 so share flow is 32 .5 pounds per inch now we will use this use shear flow to find the corresponding vertical shear in the beam so let's try a diagram this is a y this is our x direction the distance from here to the center is this is y is capital y so consider the sheer flow for selecting at the centroid of this section so they take the section above the nail joint to find the sheer flow along the join the expression for share flow at the joint interface is q equal to vq upon i.

02:27 V is the shear force, q is the first moment of area above the plane of share flow with respect to the centroid of the section and i is the moment of inertia of the section.

02:39 So that is equal to v multiplied by a y upon i a is the area above the joint y is its centroid since the section is is symmetric about x and y x is entroit is intuitively halfway through the side so y -dash is equal to summation of a y upon summation of a summation of a y is a solid y solid minus a hollow y hollow upon summation of a is a solid minus a hollow so after putting the values we'll get y dash as 2 .5 inch similarly we will find the x as 2 .5 inch as well so locate the centroid of the area above the joint interface using the central and the central distance of the area can be calculated as y is equal to d minus y minus half multiplied by d minus d upon 2d this one is the outside dimension of the box section and d is the corresponding inside dimension...
