A sinusoidal wave is sent along a string with a linear...

A sinusoidal wave is sent along a string with a linear density of $2.0 \mathrm{~g} / \mathrm{m} .$ As it travels, the kinetic energies of the mass elements along the string vary. Figure $16-37 a$ gives the rate $d K / d t$ at which kinetic energy passes through the string elements at a particular instant, plotted as a function of distance $x$ along the string. Figure $16-37 b$ is similar except that it gives the rate at which kinetic energy passes through a particular mass element (at a particular location), plotted as a function of time $t$. For both figures, the scale on the vertical (rate) axis is set by $R_{s}=10 \mathrm{~W}$. What is the amplitude of the wave?

Key Concepts

Amplitude and Its Role in Energy Transmission

The amplitude of a wave is the maximum displacement of the particles of the medium from their equilibrium position. It plays a critical role in determining the energy carried by the wave. Since both the kinetic and potential energies depend on the square of the amplitude, measuring or calculating the energy flux (or power) through the string can provide a means to determine the amplitude of the wave. In problems involving measurements of energy rates, one typically relates the observed power to the amplitude using established formulas from wave mechanics.

Energy Flux in Waves

Energy flux is the rate at which energy is transmitted through a given point or area in the medium. In the context of a string under sinusoidal oscillation, the energy flux (or power) can be linked to both the kinetic and potential energy contributions of the moving string elements. Expressions relating the average power transmitted by a sinusoidal wave typically involve the product of the linear mass density, wave speed, angular frequency, and the square of the amplitude.

Kinetic Energy in Wave Motion

Kinetic energy in wave motion refers to the energy associated with the motion of the mass elements of the medium (in this case, the string) as they oscillate. For a small segment of the string, the kinetic energy depends on the mass (derived from the linear density) and the square of the transverse velocity of that segment. The maximum transverse velocity is related to the amplitude and the angular frequency of the sinusoidal wave.

Linear Mass Density

Linear mass density is the mass per unit length of the string. It is a crucial property that affects the wave speed as well as the kinetic and potential energy distributions in the wave. In energy calculations for mechanical waves on a string, the linear mass density determines how much mass is undergoing motion at each small segment, and therefore directly influences the energy transmitted by the wave.

Sinusoidal Waves

Sinusoidal waves are periodic disturbances that are described mathematically by sine or cosine functions. They are fundamental solutions to the wave equation and serve as building blocks for more complicated motions. In the context of waves on a string, the sinusoidal form allows the use of simple harmonic motion properties, such as well-defined amplitudes, angular frequencies, and wavelengths, which are essential for analyzing energy propagation along the string.

Transcript

00:01 So in this question, we are given this graph of the kinetic energy, the rate of change for the kinetic energy versus time and versus distance for away.

00:14 And we are given a couple of parameters.

00:18 We are told what is the mass density of this rope.

00:23 And from this graph, we can read two more things.

00:26 One is, we can read that the period is two milliseconds because this graph is one period.

00:39 I mean, it looks like two periods for rs, but this is one period for the wave, because this process is when it's going from one maximum to equilibrium.

00:51 I'm assuming this maximum.

00:53 It goes to like a minimum, but then because kinetic energy is squared, it is still positive, but this is actually a minimum, and then it goes from minimum to equilibrium, and then it goes to another maximum.

01:06 So this whole thing is like one period, so that's why it's 2 milliseconds.

01:09 And similar here, this tells us the wavelength equals 0 .2 meter.

01:16 And now we are looking for what is the amplitude of this wave.

01:19 And in order to do that, we need to figure out how is rs related to the original wave.

01:25 So if you have equation 1620, now you can immediately use that, but i'm going to derive it here.

01:33 So, what is rs? rs is a rate of change for kinetic energy of the way.

01:40 So let's first look at kinetic energy.

01:41 Kinetic energy equals one half of mv square.

01:45 So in this case, m, we know the density, we know the mass density, mu.

01:50 So m is going to be mass density times less mu, mu, l, whatever it is.

01:55 It's just like some distance that we're considering.

01:59 I mean, because if we're looking for the kinetic energy, we must be looking for the kinetic energy of a fixed length of string...
