An R L C circuit includes a 3.3-μF capacitor and a 27-mH inductor. The capacitor is charged to 3

step 1 since the resistance is present in the circuit present in the circuit the circuit acts as circui

An R L C circuit includes a 3.3-μF capacitor and a 27-mH...

An $R L C$ circuit includes a $3.3-\mu \mathrm{F}$ capacitor and a $27-\mathrm{mH}$ inductor. The capacitor is charged to $35 \mathrm{~V}$, and the circuit begins oscillating. Ten full cycles later the capacitor voltage peaks at $28 \mathrm{~V}$. Find the resistance.

Key Concepts

Natural Frequency

The natural frequency of an RLC circuit is the frequency at which the circuit would oscillate if there were no energy losses (i.e., no damping). It is determined by the inductance and capacitance, typically expressed as ?? = 1/?(LC). In the presence of damping, the actual oscillation frequency is slightly lower than the natural frequency, but the natural frequency remains a key characteristic of the circuit.

Logarithmic Decrement

Logarithmic decrement is a technique used to characterize the decay of oscillations in a damped system. It involves taking the natural logarithm of the ratio of the amplitudes of any two successive peaks. This concept provides a practical measure of the damping factor and enables the determination of resistance from observed amplitude decay over a known number of oscillation cycles.

RLC Circuit

An RLC circuit consists of a resistor, an inductor, and a capacitor connected in a circuit. The energy in the circuit oscillates between the magnetic field of the inductor and the electric field of the capacitor, while the resistor dissipates energy, which influences the amplitude of the oscillations. This type of circuit is fundamental in studying oscillatory behavior in electrical and electronics engineering.

Underdamped Oscillations

In an underdamped RLC circuit, the resistance is low enough relative to the inductance and capacitance that the system oscillates but with an amplitude that decays over time due to energy loss. This behavior occurs when the damping is not so high as to prevent oscillations altogether, and it often appears as a sinusoidal oscillation multiplied by an exponential decay envelope.

Damping Factor

The damping factor in an RLC circuit quantifies the rate at which the oscillation amplitude decreases over time. It is directly related to the resistor’s value and is typically given by R/(2L) for a series RLC circuit. This parameter helps determine how quickly the energy in the circuit dissipates.
