Circuit Analysis Consider the circuit in the figure.
The currents $I_{1}, I_{2}$ and $I_{3}$ in amperes are given by the
solution of the system of linear equations.
$$\left\{\begin{aligned} 4 I_{1} &+8 I_{3}=2 \\ 2 I_{2}+8 l_{3} &=6 \\ I_{1}+I_{2}-I_{3} &=0 \end{aligned}\right.$$
Use Cramer's Rule to find the three currents.

Key Concepts

Determinants

Determinants are scalar values derived from square matrices that offer insights into the properties of the matrix, such as invertibility. In the context of Cramer's Rule, determinants are used to compute the values of unknowns in a system of linear equations by evaluating the coefficient matrix and its variations.

Cramer's Rule

Cramer's Rule is a method for solving systems of linear equations using determinants. It provides explicit formulas for each variable by expressing them as a ratio of two determinants, making it a practical tool when the coefficient matrix is non-singular.

Kirchhoff's Laws

Kirchhoff's laws, which consist of the Current Law (KCL) and the Voltage Law (KVL), are essential for analyzing circuits. KCL states that the sum of currents entering a junction equals the sum leaving it, ensuring charge conservation, while KVL asserts that the sum of voltage drops around any closed loop in a circuit is zero, reflecting energy conservation.

Circuit Analysis

Circuit analysis involves using fundamental electrical principles, such as Kirchhoff's laws, to understand and calculate the behavior of electrical circuits. This usually includes setting up and solving equations that describe the relationships among the various currents and voltages in the circuit.

System of Linear Equations

A system of linear equations consists of several linear equations involving the same set of variables. In circuit analysis, these systems typically arise from applying Kirchhoff's laws, and solving them yields the values of unknown currents or voltages in the circuit.
