Determine the shear-stress variation over the cross section...

Determine the shear-stress variation over the cross section of the thin-walled tube as a function of elevation $y$ and show that $\tau_{\max }=2 V / A,$ where $A=2 \pi \pi .$ Hint: Choose a differential area element $d A=R t d \theta .$ Using $d Q=y d A$ formulate $Q$ for a circular section from $\theta$ to $(\pi-\theta)$ and show that $Q=2 R^{2} t \cos \theta,$ where $\cos \theta=\sqrt{R^{2}-y^{2}} / R$.

Key Concepts

Shear Stress Distribution

Shear stress distribution is a fundamental concept in mechanics that explains how internal shearing forces are spread across a material's cross-sectional area. It is critical when analyzing beam and tube structures, where varying stress profiles indicate points of maximum shear and inform safe design practices.

Thin-Walled Tube Theory

The thin-walled tube theory simplifies the stress analysis in structures with a wall thickness that is much smaller than their overall dimensions. This simplification assumes that stresses are uniformly distributed across the wall thickness, allowing for easier integration and more straightforward calculations of properties such as shear stress.

Differential Area Element

A differential area element is a small portion of a surface used to perform integrations over a continuous area. By expressing the area in terms of a variable—in this case, dA = R t d? for a circular section—one can systematically sum (integrate) the contributions of all such elements to calculate physical quantities like the first moment of area.

First Moment of Area

The first moment of area, denoted by Q, is an integral measure that quantifies how a cross-sectional area is distributed relative to a given axis. It is calculated by integrating the product of the distance (from the axis) and the differential area element (dA), and is essential in determining the shear stress distribution in a structure under load.

Circular Geometry Relations

Circular geometry relations involve the trigonometric connections between angular parameters and linear dimensions in a circle. For instance, the relation cos? = ?(R² - y²) / R links the angular variable ? and the elevation y, which is critical when converting integrals from angular to vertical coordinates in the analysis of circular cross-sections.
