Every other year, the magazine Hydrocarbon Processing publishes a petrochemical handbook, which gives process-flow diagrams and data for more than 50 commercial processes. For each of the following processes in the March 1991 handbook, list the separation operations of the type given in Table 1.1 and indicate what chemical(s) is(are) being separated: (a) Linear alkylbenzene (UOP), p. 130 (b) Methyl amines (Acid-Amine Technologies), p. 133 (c) Butene-2 (Phillips), p. 144 (d) Caprolactam (SNIA), p. 150 i (e) Ethylene glycols (Scientific Design), p. 156 I (f) Styrene (Monsanto), p. 188

Every other year, the magazine Hydrocarbon Processing publishes a petrochemical handbook, which gives process-flow diagrams and data for more than 50 commercial processes. For each of
the following processes in the March 1991 handbook, list the separation operations of the type given in Table 1.1 and indicate what
chemical(s) is(are) being separated:
(a) Linear alkylbenzene (UOP), p. 130
(b) Methyl amines (Acid-Amine Technologies), p. 133
(c) Butene-2 (Phillips), p. 144
(d) Caprolactam (SNIA), p. 150 i
(e) Ethylene glycols (Scientific Design), p. 156 I
(f) Styrene (Monsanto), p. 188

Key Concepts

Petrochemical Process Design

This concept encompasses the overall strategy and methodology used to develop industrial processes for transforming raw materials into valuable chemical products. It involves integrating various process units, including multiple separation operations, to achieve efficient, cost-effective, and sustainable production. The design stage is critical in optimizing the process flow and ensuring that product quality and yield targets are met while managing energy and material balances.

Chemical Separation Principles

These principles form the foundation for designing effective separation processes. They involve the exploitation of differences in chemical and physical properties—such as relative volatility, solubility, and molecular size—to facilitate the selective removal or concentration of chemicals. Mastery of these principles enables engineers to choose and integrate the right combination of separation techniques within larger petrochemical processes.

Process Flow Diagrams

Process flow diagrams (PFDs) are schematic representations that outline the sequence of operations within a chemical process, illustrating the connections and interactions between different unit operations, including separation steps. They provide a roadmap for engineers to understand the overall process, pinpoint where separations occur, and define the flow of materials and energy throughout the system.

Separation Operations

These are unit processes used in chemical engineering to isolate or purify individual components from mixtures. They rely on differences in physical or chemical properties—such as boiling point, solubility, density, or volatility—to effectively split feed streams into product and waste streams. Examples include distillation, extraction, absorption, and crystallization, among others. Understanding which operation to use is key in optimizing efficiency and purity in chemical processes.

Transcript

00:01 Part a, linear alkalobenzene, uop.

00:22 The uop lab process includes several classic hydrocarbon separations.

00:59 After linear alkalization, the process requires purification of both the kerosene feedsock and the produced alkalobenzene.

01:56 The major separation operations, fractional distillation, separates kerosene into light ends, paraffins, and the linear alkalobenzene product stream.

02:29 It separates unreacted benzene, monoalkal benzene, and heavy acolyte.

02:36 Liquid liquid extraction used in the uop -molex steps for extracting normal paraffins from kerosene, and drying.

02:58 It removes water from solvent or feed streams.

03:04 The primary chemicals separated, normal paraffin versus branched paraffins, benzene and unreacted aromatics, linear alkaline product, heavy alkaliate and light ends, part b, methyl amines, acid amine technologies, commercial methylamine plants produce mixtures of monomethylamine mma, dimethylene dma, and trimetylene -mene tma, which must be separated.

05:49 The major separation operations, fractional distillation, the primary means of separating mma, dma, and tma due to their distinct boiling points.

06:18 It purifies ammonia, methanol, and water from the reaction mixture.

06:26 Absorption or stripping.

06:36 It's used to recover light gases such as ammonia or methanol and to remove water.

06:43 The primary chemicals separated, mma, dma, and tma, ammonia, water, and methanol, and light gases or inerts.

07:28 Part c, bootine two, phillips.

07:46 The phillips bootine two process involves isomerizing normal bootines, and then separating cis 2 butine, trans 2 butine, and residual 1 butine.

08:45 The major separation operations, fractional distillation, this separates one butene, cis -2butene and trans -2 -butene, and it removes propane and c -5 positive hydrocarbons.

09:20 Absorption or stripping, it's used for light hydrocarbon recovery.

09:34 No other phase -splitting operations are typical, as it's mostly controlled distillation.

09:42 The primary chemicals separated, one butene, cis -2 -butene, and trans -butene -2 -butene, propane or propylene c5 positive heavies...
