(III) Consider the network of resistors shown in Fig. $19-40 .$ Answer qualitatively: $(a)$ What happens to the voltage across each resistor when the switch $S$ is closed? (b) What happens to the current through each when the switch is closed? $(c)$ What happens to the power output of the battery when the switch is closed? (d) Let $R_{1}=R_{2}=R_{3}=R_{4}=125 \Omega$ and $V=22.0 \mathrm{~V}$. Determine the current through each resistor before and after closing the switch. Are your qualitative predictions confirmed?

(III) Consider the network of resistors shown in Fig. $19-40 .$ Answer qualitatively: $(a)$ What happens to the voltage across each resistor when the switch $S$ is closed? (b) What happens to the current through each when the switch is closed? $(c)$ What happens to the power output of the battery when the switch is closed?
(d) Let $R_{1}=R_{2}=R_{3}=R_{4}=125 \Omega$ and $V=22.0 \mathrm{~V}$.
Determine the current through each resistor before and after closing the switch. Are your qualitative predictions confirmed?

Key Concepts

Ohm's Law

Ohm's Law is a fundamental principle in electrical circuits that establishes the relationship between voltage, current, and resistance. It states that the current flowing through a resistor is directly proportional to the voltage across it and inversely proportional to its resistance. This law is essential for analyzing how changes in circuit configuration, such as closing a switch, affect current and voltage distribution in a circuit.

Series and Parallel Circuits

Series and parallel circuit configurations describe how components like resistors are arranged in a circuit. In a series arrangement, components share the same current, and the total voltage is divided among them. In contrast, in a parallel arrangement, all components share the same voltage while the current is divided among them. Understanding these configurations is crucial for predicting qualitative and quantitative changes in voltage and current when circuit connections are modified.

Kirchhoff's Circuit Laws

Kirchhoff's Circuit Laws consist of two rules: the current law (KCL), which states that the total current entering a junction equals the total current leaving it, and the voltage law (KVL), which states that the sum of voltage drops around any closed loop in a circuit is zero. These laws are instrumental in analyzing complex circuits and understanding how closing a switch alters the overall distribution of currents and voltages throughout the network.

Switching in Electrical Circuits

Switching refers to the process of opening or closing a circuit, which changes the connectivity of its elements. When a switch is closed, it can either complete a circuit or add a parallel or series branch, thereby altering the voltage drops, currents through resistors, and overall power consumption. This concept is foundational for predicting qualitative changes in circuit behavior under different configurations.

Power in Electrical Circuits

Power in electrical circuits is determined by the product of voltage and current, and it indicates the rate at which energy is delivered or dissipated. When circuit configurations change, such as through the closing of a switch, the redistribution of currents and voltages can lead to changes in the power output of a battery and the power dissipated across resistive elements. Understanding the relationship between these elements helps in predicting how modifications in the circuit affect overall energy consumption.
