In the circuit in the figure, the capacitors are completely uncharged. The switch is then closed for a long time. a) Calculate the current through the $4.00-\Omega$ resistor. b) Find the potential difference across the $4.00-\Omega, 6.00-\Omega$, and $8.00-\Omega$ resistors. c) Find the potential difference across the $1.00-\mu \mathrm{F}$ capacitor.

In the circuit in the figure, the capacitors are completely uncharged. The switch is then closed for a long time.
a) Calculate the current through the $4.00-\Omega$ resistor.
b) Find the potential difference across the $4.00-\Omega, 6.00-\Omega$, and $8.00-\Omega$ resistors.
c) Find the potential difference across the $1.00-\mu \mathrm{F}$ capacitor.

Key Concepts

Series and Parallel Resistor Combinations

Analyzing circuits often requires combining resistors in series and parallel to simplify the circuit into equivalent resistances. In series, resistances add directly, while parallel combinations require taking the reciprocal of the sum of reciprocals. This process helps in reducing complex resistor networks into simpler, manageable forms for analysis.

Kirchhoff's Laws

Kirchhoff's Current Law (KCL) and Kirchhoff's Voltage Law (KVL) are fundamental for analyzing electrical circuits. KCL states that the sum of currents entering a node is equal to the sum of currents leaving it, while KVL states that the sum of the potential differences in any closed loop must equal zero. These principles are vital in determining unknown currents and voltages within a circuit.

Resistive Voltage Divider

The resistive voltage divider is a circuit configuration in which a set of resistors in series divides an input voltage into smaller voltages proportional to the resistor values. This principle is used to calculate the potential difference across individual resistors when the resistors are connected in series in a steady-state circuit.

Transient and Steady-State Behavior

In circuits containing capacitors, switching actions create transient conditions that eventually settle into a steady state. Initially, when a switch is closed, capacitors begin charging, creating a time-dependent behavior in the circuit. After a long time, the circuit reaches steady state where the capacitor voltage remains constant, and current flow through the capacitor ceases, simplifying the circuit analysis to a static condition.

Capacitors in DC Steady State

Under DC steady-state conditions, a capacitor behaves as an open circuit because once fully charged, no further current flows through it. This key characteristic allows one to simplify DC circuit analysis by effectively removing the capacitors from the current path, enabling the focus on resistive elements only.

Transcript

00:01 Hi, in the given problem here there is a combination of resistors with a capacitor.

00:10 This resistor is having a resistance of 6 .00 om.

00:16 Then here there is another resistor having a resistance of 4 .00 om along with a capacitor in series, having a capacitance of 1 .00 micro ferret.

00:31 Then a battery providing a potential of 10 .0 volt and finally a switch s.

00:50 Now it is given that in the first part of the problem the switch has been closed for a long time.

00:58 So when the switch has been closed for a long time.

01:13 A long time the capacitor will be fully charged so there will be no current through the capacitor means in the branch which is having a capacitor there will be no current so we may ignore that branch hence the current passing through the resistance for oom is 0.

02:06 Now if we consider these currents to be here this is i coming out of this battery then the current passing through this resistor or we can say through capacitor is i1 and that passing through here sorry there is also a resistor having a resistance of 8 .00 micro sorry this is oom.

02:33 So the current passing through this 8 .00 om is i 2 suppose it to be.

02:39 So in the first part of the problem the magnitude of this current i 1 comes out to be 0.

02:47 This is the answer for the first part of this problem.

02:50 Now in the second part of the problem we have to find the potential drops taking place across this 6 -oom, this 6 -oom resistor and this 8 -oom.

03:03 Resistor.

03:04 So for this we redraw the circuit diagram excluding the central branch because there is no current passing through it.

03:15 So there are only two resistors 6 .00 om and 8 .00 om in this effective circuit.

03:31 The switch is closed already...
