In the given figure, the mass of blocks $A$ and $B$ are $m_{1}$ and $m_{2}$ respectively, the pulley is circular disc of mass $m$ and radius $r$. The pulley is free to rotate about $O$. No friction exists between $A$ and $B$ and the floor. The magnitude of acceleration of block $B$ is $a_{0}$. Then the magnitude of acceleration of $A$ is : (a) $a_{0}$ (b) $2 a_{0}$ (c) $\sqrt{2} a_{0}$ (d) $g$

In the given figure, the mass of blocks $A$ and $B$ are $m_{1}$ and $m_{2}$ respectively, the pulley is circular disc of mass $m$ and radius $r$. The pulley is free to rotate about $O$. No friction exists between $A$ and $B$ and the floor. The magnitude of acceleration of block $B$ is $a_{0}$. Then the magnitude of acceleration of $A$ is :
(a) $a_{0}$
(b) $2 a_{0}$
(c) $\sqrt{2} a_{0}$
(d) $g$

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Rotational Dynamics of a Massive Pulley

In real systems the pulley has a non?negligible mass and moment of inertia, meaning it resists changes in its rotational state. Incorporating the pulley's rotational dynamics is critical, as its inertia influences the force-acceleration relationships in the system and affects how the accelerations of the connected masses are related.

Pulley Kinematics and Rolling Without Slipping

When a rope does not slip on the pulley, there is a direct relationship between the linear speed (and acceleration) of any point on the rim of the pulley and its angular speed (and angular acceleration). This kinematic condition allows one to relate the rotational motion of the pulley to the translational motion of the masses connected by the rope.

Inextensible String Constraint

In mechanical systems using a non?stretchable rope, the total length of the string remains constant. This constraint couples the displacements, velocities, and accelerations of all the bodies to which the string is attached. Analyzing this relationship is essential in determining how motion in one part of the system affects motion in another.
