Iridescent peacock feathers are shown in Figure P 27.68 a (page 938 ). The surface of one micros

step 1 In the formula, 2d, sine theta equals m times lambda, we can show that sometimes it can appear t

Iridescent peacock feathers are shown in Figure P 27.68 a...

Iridescent peacock feathers are shown in Figure $\mathrm{P} 27.68 \mathrm{a}$ (page 938 ). The surface of one microscopic barbule is composed of transparent keratin that supports rods of dark brown melanin in a regular lattice, represented in Figure $\mathrm{P} 27.68 \mathrm{b}$. (Your fingernails are made of keratin, and melanin is the dark pigment giving color to human skin. In a portion of the feather that can appear turquoise (blue-green), assume the melanin rods are uniformly separated by $0.25 \mu \mathrm{m},$ with air between them. (a) Explain how this structure can appear turquoise when it contains no blue or green pigment. (b) Explain how it can also appear violet if light falls on it in a different direction. (c) Explain how it can present different colors to your two eyes simultaneously, which is a characteristic of iridescence. (d) A compact disc can appear to be any color of the rainbow. Explain why the portion of the feather in Figure $\mathrm{P} 27.68 \mathrm{b}$ cannot appear yellow or red. (e) What could be different about the array of melanin rods in a portion of the feather that does appear to be red?

Key Concepts

Structural Coloration

This is the phenomenon where color arises not from pigments but from micro- or nanostructures that manipulate incoming light. These structures cause specific wavelengths to interfere constructively while others interfere destructively, producing vivid colors through physical optical effects rather than chemically produced pigments.

Light Interference

Interference occurs when light waves superpose, and the specific geometry of the structure leads to constructive or destructive interference of different wavelengths. Only certain wavelengths satisfy the conditions for constructive interference, which explains why the structure reflects particular colors even in the absence of a corresponding pigment.

Bragg Diffraction/Reflection

Bragg’s law describes the condition under which light reflected from a periodic structure will interfere constructively. The inter-rod spacing relates directly to the wavelengths that are most strongly reflected, so if the spacing is comparable to the wavelength of light, only specific colors will be enhanced, while others, such as yellow or red, may not meet the constructive interference condition.

Iridescence

Iridescence refers to the change in observed color with the angle of illumination or viewing. In structured materials, the effective path difference for reflected light varies with angle, allowing different wavelengths to be reinforced in different directions. This angular dependence can result in simultaneous observation of different colors from slightly different viewpoints.

Periodicity in Optical Structures

The regular, repeating arrangement of elements on a microscopic scale creates a photonic structure that selectively filters and reflects light. The dimensional scale of the periodic elements relative to the wavelength of visible light determines the color that is observed, and slight modifications in the pattern or spacing can shift the reflected wavelength, thus changing the apparent color.
