Reconsider the mechanism of Prob. 6 / 232 . If crank OA now...

Reconsider the mechanism of Prob. $6 / 232 .$ If crank OA now starts from rest and acquires a speed of 60 rev/min in one complete revolution with constant angular acceleration, determine and plot the torque $M$ which must be applied to the crank over the range $0 \leq \theta \leq 2 \pi .$ What is the largest magnitude $M$ which occurs during this motion, and at what angle $\theta$ does it occur? Additionally, plot the magnitude of the force in each pin over this range and state the maximum magnitude of each pin force along with the corresponding crank angle $\theta$ at which it occurs.

Key Concepts

Rotational Kinematics

Rotational kinematics is the study of motion in terms of angular displacement, angular velocity, and angular acceleration. It provides the framework to relate the time evolution of rotation, such as how a rotating body's speed changes from rest under constant angular acceleration, without initially considering the forces or torques involved.

Constant Angular Acceleration

When a rotating system undergoes constant angular acceleration, its angular velocity increases steadily over time. This condition allows the use of simplified kinematic equations analogous to those in linear motion to link angular displacement, velocity, and acceleration over a specific interval, such as one complete revolution.

Torque and Moment of Inertia

Torque is the rotational equivalent of force and is responsible for producing angular acceleration in a rotating body. The moment of inertia, which depends on the mass distribution relative to the axis of rotation, quantifies the resistance of an object to changes in its rotational state. Their relationship, given by Newton’s second law for rotation (torque = moment of inertia × angular acceleration), is key to analyzing rotational dynamics.

Force Analysis in Mechanisms

Analyzing forces in mechanisms involves determining the magnitudes and directions of forces acting at various points, such as pins or joints, as the mechanism moves. This analysis often includes decomposing forces into components and applying equilibrium or dynamic equations to find internal forces, which are crucial for understanding mechanical loads and performance.

Graphical Analysis of Dynamic Quantities

Graphical analysis involves plotting variables like torque or the magnitude of forces versus angles or time, which helps visualize how these quantities vary throughout the motion of a system. Such plots facilitate the identification of peak values and corresponding conditions, enhancing insights into the mechanical behavior and design requirements of the system.
