The four-bar mechanism of Prob. $6 / 108$ is repeated here. The coupler $A B$ has a mass of $7 \mathrm{kg}$, and the masses of crank $O A$ and the output arm $B C$ may be neglected. Determine and plot the torque $M$ which must be applied to the crank at $O$ in order to keep the speed of the crank steady at 60 rev/min over the range $0 \leq \theta \leq 2 \pi .$ What is the largest magnitude $M$ which occurs during this motion, and at what angle $\theta$ does it occur? Additionally, plot the magnitude of the force on each pin over this range and state the maximum magnitude of each pin force along with the corresponding crank angle $\theta$ at which it occurs.

Key Concepts

Force Analysis in Pin Joints

Pin joints impose reaction forces without moments due to their ability to allow rotation. Analyzing these forces over a motion cycle is key to ensuring that the design can withstand the maximum loads encountered. This involves resolving forces into components and determining their magnitudes as the system evolves.

Free Body Diagrams and Equilibrium Analysis

Constructing free body diagrams is fundamental for isolating individual components and accounting for all acting forces and torques. Equilibrium analysis then allows for setting up the equations of motion or static equilibrium conditions, which help in computing the required torque and the resultant forces on the joints throughout the mechanism’s cycle.

Rigid Body Dynamics

Rigid body dynamics focuses on how forces and torques affect the motion of bodies that do not deform. In the context of a mechanism with rotating links, it is crucial to apply principles such as Newton’s laws for rotation to determine the necessary applied torques to sustain a constant angular velocity.

Kinematics of Four-Bar Mechanisms

This concept involves the geometric and motion relationships within a closed-loop linkage system. Understanding how the angles, angular velocities, and accelerations of the bars are interrelated is essential for predicting the motion of any point or link in the mechanism over a complete cycle.

Inertial Forces and Moments

Inertial effects arise from the mass and acceleration of the moving components. When analyzing a mechanism where one link carries mass, the distribution of that mass leads to inertial forces and moments (torques) that must be overcome by the applied input, particularly when the motion changes direction or speed, even if the speed is constant overall.
