The four-bar mechanism lies in a vertical plane and is controlled by crank $O A$ which rotates counterclockwise at a steady rate of 60 rev/min. Determine the torque $M$ which must be applied to the crank at $O$ when the crank angle $\theta=45^{\circ} .$ The uniform coupler $A B$ has a mass of $7 \mathrm{kg}$, and the masses of crank $O A$ and the output arm $B C$ may be neglected.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Four-Bar Mechanism

A four-bar mechanism is a planar closed-chain system consisting of four rigid links connected by rotary joints. Its geometry imposes constraints on movement that simplify the analysis of complex motion, making it a fundamental example in the study of mechanical linkages and motion transfer.

Angular Kinematics

Angular kinematics deals with the relationships between angular displacement, angular velocity, and angular acceleration. In mechanisms operating in a plane, this analysis is essential to convert input rates (such as revolutions per minute) into radian measures and to understand the motion relationships between interconnected links.

Rotational Dynamics

Rotational dynamics focuses on the relationship between applied torques and the resulting angular accelerations, taking into account the moment of inertia of the components. This concept is vital for determining the necessary torque to overcome inertial effects, particularly in systems with rotating elements.

Dynamic Force Analysis

Dynamic force analysis involves evaluating the inertial forces, centripetal forces, and gravitational effects acting on moving bodies. In mechanisms like the four-bar system, it is crucial to balance these forces to compute the net moments and required input torques for sustaining prescribed motion conditions.
