The following equations are obtained from a force diagram of a rectangular farm gate, supported by two hinges on the left-hand side. A bucket of grain is hanging from the latch. $$-A+C=0$$ $$+B-392 \mathrm{N}-50.0 \mathrm{N}=0$$ $$A(0)+B(0)+C(1.80 \mathrm{m})-392 \mathrm{N}(1.50 \mathrm{m})$$ $$-50.0 \mathrm{N}(3.00 \mathrm{m})=0$$ (a) Draw the force diagram and complete the statement of the problem, specifying the unknowns. (b) Determine the values of the unknowns and state the physical meaning of each.

The following equations are obtained from a force diagram of a rectangular farm gate, supported by two hinges on the left-hand side. A bucket of grain is hanging from the latch.
$$-A+C=0$$
$$+B-392 \mathrm{N}-50.0 \mathrm{N}=0$$
$$A(0)+B(0)+C(1.80 \mathrm{m})-392 \mathrm{N}(1.50 \mathrm{m})$$
$$-50.0 \mathrm{N}(3.00 \mathrm{m})=0$$
(a) Draw the force diagram and complete the statement of the problem, specifying the unknowns. (b) Determine the values of the unknowns and state the physical meaning of each.

Key Concepts

Moment Arm

The moment arm is the perpendicular distance from the pivot point to the line of action of a force. Calculating the moment arm allows us to determine the torque produced by a force, which is key to setting up the moment equilibrium equations in static problems.

Moment (Torque) Equilibrium

Moment equilibrium, or torque equilibrium, is achieved when the sum of all moments about any pivot point is zero, preventing the body from experiencing rotational motion. This condition is essential for solving problems involving forces that cause rotation, such as those acting on a hinged gate.

Static Equilibrium

Static equilibrium refers to the condition in which a body remains at rest because the total sum of forces and the total sum of moments (torques) acting on it are zero. This concept is fundamental in mechanics problems, ensuring that the structure, like the gate, does not translate or rotate under the applied loads.

Reaction Forces

Reaction forces are the forces exerted by supports, hinges, or connections that counterbalance the applied loads on a structure. They are unknowns that must be determined to satisfy the conditions of static equilibrium, guaranteeing that the net force acting on the system is zero.

Free Body Diagram

A free body diagram is a simplified illustration that isolates a body and shows all the external forces and moments acting on it. This diagram is crucial in mechanics, as it forms the basis for setting up equilibrium equations by clearly depicting where forces are applied and their directions.

Transcript

00:01 And this problem is kind of actually interesting because we're given the equations and then basically asked to construct the system that those equations would be derived from.

00:14 So we're told that we have a farm gate that's supported by two hinges on the left side that a bucket of grain is hanging from the latch.

00:22 So i just kind of represented the gate as kind of a triangle here.

00:29 Maybe there's an extra piece here i don't know but then the weight the back basket of grain is the bucket of grain is supported over here and then the we're told that we know that a so we have three back you have three components or three force components in this problem a b and c so we're told that minus a plus c equals zero well, that's a balance of forces and i said that okay if this is c and this is a then in the horizontal direction minus c must be equal to a and i've drawn this should be an arrow over here and not on the other side it is minus c so minus c plus a equals 0 is the force balance in the horizontal direction.

01:43 We're also told that b minus 392 minus 50 newton is 0.

01:49 So that's a force balance in the vertical direction.

01:53 So that must be the force at one of these hinges.

01:56 Or basically, we can't resolve what the force on each hinge is, but we can resolve what the net force on both hinges are.

02:04 Just assume that one hinge has a vertical force and this one is free to slide up and down.

02:12 So that basically tells us what the weights are.

02:16 So the weight of the gate itself is 392 newt and the weight of the bucket is 50 newtons.

02:26 Now the last equation is the moment equation and we can know that because we can see that the terms are moments and not forces...
