The force applied at the handle of the rigid lever causes...

The force applied at the handle of the rigid lever causes the lever to rotate clockwise about the pin $B$ through an angle of $2^{\circ}$. Determine the average normal strain developed in each wire. The wires are unstretched when the lever is in the horizontal position.

Key Concepts

Geometric Analysis of Deformation

Geometric analysis involves using the principles of geometry to determine the displacements and strains that occur as a result of applied loads or rotations. This approach is essential when relating the rotational motion of a lever to the corresponding elongation or compression in attached components, such as wires, by linking angular displacement to linear changes in length.

Reference Configuration

This concept involves the initial, undeformed state of a material or structure against which subsequent deformations are measured. When a system, such as a set of wires attached to a lever, is described as being unstretched in its horizontal position, that configuration serves as the reference state for calculating strains induced by later deformations.

Rigid Body Rotation

This concept refers to the motion where all points in a body move in circular paths about a common axis without undergoing any deformation. In problems involving levers or similar mechanisms, understanding rigid body rotation is critical because the displacement of any point on the lever is directly related to its distance from the axis of rotation and the angle through which the lever rotates.

Normal Strain

Normal strain is a measure of deformation representing the relative change in length of a material element. It is defined as the ratio of the change in length to the original length. In contexts involving tension or compression, normal strain is used to quantify how much a material has stretched or compressed under an applied load.
