The reverse-biased saturation current is a function of...

The reverse-biased saturation current is a function of temperature. (a) Assuming that $I_{x}$ varies with temperature only from the intrinsic carrier concentration, show that we can write $I_{x}=C T^{3} \exp \left(-E_{g} / k T\right)$ where $C$ is a constant and a function only of the diode parameters. (b) Determine the increase in $I_{x}$ as the temperature increases from $T=300 \mathrm{~K}$ to $T=400 \mathrm{~K}$ for a $(i)$ germanium diode and (ii) silicon diode.

Key Concepts

Diode Parameters and Constant C

The constant C in the expression I_x = C T^3 exp(-E_g/(kT)) encapsulates all diode-specific parameters such as junction area, material properties, carrier mobilities, and effective density of states. While the temperature dependence is dictated by fundamental semiconductor physics, C represents the intrinsic characteristics of the diode that modulate the absolute magnitude of the saturation current.

Bandgap Energy

The bandgap energy (E_g) is a fundamental property of a semiconductor that represents the energy difference between the valence and conduction bands. It dictates the minimum energy required for an electron to transition and contribute to conduction. In the reverse saturation current expression, the bandgap appears in the exponential factor, underscoring its role in limiting thermally generated carriers at lower temperatures and allowing more carriers at higher temperatures.

Exponential Temperature Dependence (Arrhenius Behavior)

The exponential term exp(-E_g/(kT)) in semiconductor processes is indicative of Arrhenius behavior, where the probability of thermally exciting carriers over an energy barrier (the bandgap E_g) increases dramatically with temperature. This behavior is characteristic of many thermally activated processes, and in the context of the reverse bias current, it explains the sharp increase in current with temperature.

Intrinsic Carrier Concentration

In a semiconductor, the intrinsic carrier concentration refers to the number of electrons and holes generated thermally without any doping. It is highly temperature-dependent, with its mathematical form including a power law (typically T^(3/2)) and an exponential factor exp(-E_g/(2kT)), reflecting the balance between the available thermal energy and the energy gap that electrons need to overcome. This concept is central because it determines the level of carrier generation in intrinsic materials and influences many semiconductor properties.

Effective Density of States

The effective density of states in the conduction and valence bands represents the number of states available per unit volume for electrons and holes, respectively. This quantity also has a temperature dependence, generally scaling as T^(3/2), and when combined with the intrinsic carrier concentration, it contributes to the overall temperature dependence observed in semiconductor currents.

Reverse-Bias Saturation Current

The reverse-bias saturation current in a diode is the small current that flows when a diode is reverse biased. It is predominantly determined by the diffusion of minority carriers and is extremely sensitive to temperature changes. Since both carrier generation and the effective density of states scale with temperature, the reverse saturation current reflects a strong temperature dependence that includes both a polynomial (T^3) and an exponential exp(-E_g/(kT)) factor.
