The rod is made of $\mathrm{A} 992$ steel and has a diameter of 0.25 in. If the rod is 4 ft long when the springs are compressed 0.5 in. and the temperature of the rod is $T=40^{\circ} \mathrm{F}$, determine the force in the rod when its temperature is $T=160^{\circ} \mathrm{F}$.

Key Concepts

Thermal Expansion

Thermal expansion refers to the increase in length, area, or volume of a material when its temperature increases. In solids, for every degree of temperature rise, there is a predictable, usually small, change in dimensions based on the material’s properties. This concept is critical when analyzing structural elements that experience temperature variations, as these dimensional changes can introduce additional stresses if the expansion is constrained.

Coefficient of Thermal Expansion

The coefficient of thermal expansion quantifies the rate at which a material expands per unit length for a unit increase in temperature. It is an intrinsic material property that helps predict how much a component will change its dimensions as the temperature varies. In engineering problems involving thermal loading, knowing this coefficient allows for the calculation of thermal strains that contribute to overall deformation and stress.

Young’s Modulus and Hooke’s Law

Young’s modulus is a measure of a material’s stiffness and is a central part of Hooke’s law, which states that, within the elastic limit, the strain in a material is directly proportional to the applied stress. These concepts are used to relate the mechanical deformation (strain) observed in a component to the internal forces (stress) and external loads, providing a framework for analyzing how materials respond to mechanical and thermally induced loads.

Axial Stress-Strain Relationship

In problems involving rods or bars under axial loading, the stress-strain relationship becomes vital. It links the force acting along the length of a member to the resulting deformation, considering both the material properties and the geometry of the cross-section. This relationship is essential for evaluating how a change in temperature, which induces thermal strain, interacts with mechanically applied loads to produce overall deformation or internal forces.

Interaction Between Thermal Effects and Mechanical Constraints

In many structural applications, thermal expansion occurs concurrently with imposed mechanical constraints—such as from attached springs or fixed supports—that restrict free expansion. This interaction results in the development of thermal stresses as the material is forced to accommodate both the thermal and mechanical deformations. Analyzing this interplay is key to determining the force in a component when temperature varies, ensuring that the design maintains structural integrity under combined thermal and mechanical loads.
