The steam generator of a vapor power plant can be considered for simplicity to consist of a combustor unit in which fuel and air are burned to produce hot combustion gases, followed by a heat exchanger unit where the cycle working fluid is vaporized and superheated as the hot gases cool. Consider water as the working fluid undergoing the cycle of Problem 8.13. Hot combustion gases, which are assumed to have the properties of air, enter the heat exchanger portion of the steam generator at $1200 \mathrm{~K}$ and exit at $500 \mathrm{~K}$ with a negligible change in pressure. Determine for the heat exchanger unit (a) the net rate at which exergy is carried in by the gas stream, in $\mathrm{kW}$. (b) the net rate at which exergy is carried out by the water stream, in $\mathrm{kW}$. (c) the rate of exergy destruction, in $\mathrm{kW}$. (d) the exergetic efficiency given by Eq. $7.45$. Let $T_{0}=15^{\circ} \mathrm{C}, p_{0}=0.1 \mathrm{MPa}$.

The steam generator of a vapor power plant can be considered for simplicity to consist of a combustor unit in which fuel and air are burned to produce hot combustion gases, followed by a heat exchanger unit where the cycle working fluid is vaporized and superheated as the hot gases cool. Consider water as the working fluid undergoing the cycle of Problem 8.13. Hot combustion gases, which are assumed to have the properties of air, enter the heat exchanger portion of the steam generator at $1200 \mathrm{~K}$ and exit at $500 \mathrm{~K}$ with a negligible change in pressure. Determine for the heat exchanger unit
(a) the net rate at which exergy is carried in by the gas stream, in $\mathrm{kW}$.
(b) the net rate at which exergy is carried out by the water stream, in $\mathrm{kW}$.
(c) the rate of exergy destruction, in $\mathrm{kW}$.
(d) the exergetic efficiency given by Eq. $7.45$.
Let $T_{0}=15^{\circ} \mathrm{C}, p_{0}=0.1 \mathrm{MPa}$.

Key Concepts

Heat Exchanger Analysis

A heat exchanger is a device used to transfer thermal energy between two or more fluids at different temperatures without mixing them. In thermodynamic cycles, heat exchangers are critical for processes such as vaporization and superheating. Analyzing heat exchangers involves understanding the energy and exergy exchanges between the fluids, which helps in identifying inefficiencies and potential improvements in system performance.

Exergetic Efficiency

Exergetic efficiency is defined as the ratio of the useful exergy output to the exergy input of a system. It is a performance metric that indicates how effectively a system converts available energy into useful work, taking into account the losses due to irreversibilities. This concept is crucial in optimizing and comparing the performance of energy conversion devices such as heat exchangers in power plants.

Exergy

Exergy represents the maximum useful work that can be extracted from a system as it equilibrates with its environment. It is an important concept in thermodynamics because it provides a measure of how much energy is truly available for conversion into work, rather than simply being a measure of total energy content. Exergy takes into account the quality of energy and the environmental reference state, making it essential to analyze real-world processes that involve irreversibilities.

Exergy Balance

An exergy balance is a fundamental tool in analyzing thermodynamic systems, similar to an energy balance but focused on work potential rather than just energy quantity. It accounts for the exergy entering and leaving a control volume, while also factoring in the destruction of exergy due to irreversibilities. This balance is used to quantify net exergy flows and to determine the performance of components such as heat exchangers.

Exergy Destruction

Exergy destruction quantifies the loss of work potential due to irreversibilities, such as friction, unrestrained expansion, and heat transfer across finite temperature differences. It is directly related to the generation of entropy in a system; therefore, minimizing exergy destruction is key to improving the efficiency of a process. Understanding where and how exergy destruction occurs helps in designing more efficient energy conversion systems.
