Two $80-\mathrm{N}$ forces are applied as shown to the corners $B$ and $D$ of a rectangular plate. ( $a$ ) Determine the moment of the couple formed by the two forces by resolving each force into horizontal and vertical components and adding the moments of the two resulting couples. (b) Use the result obtained to determine the perpendicular distance between lines $B E$ and $D F$.

Two $80-\mathrm{N}$ forces are applied as shown to the corners $B$ and $D$ of a rectangular plate. ( $a$ ) Determine the moment of the couple formed by the two forces by resolving each force into horizontal and vertical components and adding the moments of the two resulting couples.
(b) Use the result obtained to determine the perpendicular distance between lines $B E$ and $D F$.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Perpendicular Distance in Moment Calculations

When determining the moment produced by forces, identifying and using the perpendicular distance – the shortest distance from a force’s line of action to the pivot point or reference line – is crucial. This distance, often called the moment arm, simplifies the calculation, as the moment is directly proportional to both the magnitude of the force and this distance.

Moment of a Couple

A couple consists of two equal and opposite forces whose lines of action are parallel but separated by a distance, causing a pure rotational effect. The moment (or torque) of a couple is computed as the product of one of the forces and the perpendicular distance between the lines of action. This moment is independent of the point about which it is measured and is fundamental in the study of rotational dynamics.

Force Resolution

This concept involves breaking a force into its orthogonal components (typically horizontal and vertical) using trigonometric relationships. Resolving forces is essential for analyzing equilibrium and the resultant effects of forces when multiple directions are involved, as it simplifies the calculation of moments and net forces acting on a body.
