Two converging lenses (f1=9.00 cm and f2=6.00 cm) are separated by 18.0 cm . The lens on the l

step 1 So we have two lenses, L1, and the other lens is L2. The focal length of L1 is 9 centimeter. The

Two converging lenses (f1=9.00 cm and f2=6.00 cm) are...

Two converging lenses $\left(f_{1}=9.00 \mathrm{cm} \text { and } f_{2}=6.00 \mathrm{cm}\right)$ are separated by 18.0 $\mathrm{cm}$ . The lens on the left has the longer focal length. An object stands 12.0 $\mathrm{cm}$ to the left of the left-hand lens in the combination. (a) Locate the final image relative to the lens on the right. (b) Obtain the overall magnification. (c) Is the final image real or virtual? With respect to the original object, (d) is the final image upright or inverted and (e) is it larger or smaller?

Key Concepts

Real and Virtual Images

Real and virtual images are distinguished by whether the light rays actually converge to form the image. A real image forms when converging rays meet at a point, and its position can be captured on a screen. In contrast, a virtual image appears to form at a location where the rays do not physically converge—they only appear to do so when extended back—often resulting in an image that cannot be projected onto a screen.

Image Orientation and Size Determination

Image orientation and size are direct outcomes of the lens system's magnification. A negative magnification typically indicates that the image is inverted relative to the object, whereas a positive value means it is upright. Additionally, the absolute value of the magnification factor tells us whether the final image is larger or smaller than the original object, providing further qualitative insight into the imaging process.

Overall Magnification Calculation

In multi-lens systems, the overall magnification is determined by multiplying the magnifications produced by each lens. The individual lens magnification is defined as the ratio of the image distance to the object distance (with appropriate sign), and the combined effect gives insight into the size and orientation of the final image relative to the original object.

Sequential Lens Imaging

Sequential lens imaging involves analyzing systems that contain more than one lens by treating the image produced by the first lens as a virtual object for the second lens. This step-by-step approach is essential for multi-element optical systems as it simplifies the calculation of the final image position by applying the thin lens equation successively.

Sign Conventions in Optics

Sign conventions are critical in optics for consistently determining the direction and nature of distances and focal lengths. They dictate that real distances (object distances and image distances from the lens) are positive when measured in the direction of the incident or emergent light, while virtual distances can be negative. These conventions ensure correct application of the thin lens equation across different optical setups.

Thin Lens Equation

The thin lens equation, 1/f = 1/d_o + 1/d_i, is a fundamental relation in geometrical optics that connects an object's distance (d_o), its image's distance (d_i), and the focal length of a lens (f). This equation allows for the calculation of where an image will form given a lens’s focal length and the position of an object relative to the lens.
