When a double slit is illuminated with light of wavelength $510 \mathrm{~nm}$, the interference maxima on a screen $2.4 \mathrm{~m}$ away gradually decrease in intensity on either side of the $2.40-\mathrm{cm}$ -wide central maximum and reach a minimum in a spot where the fifth-order maximum is expected. (a) What is the width of the slits? (b) How far apart are the slits?

Key Concepts

Double-Slit Interference

Double-slit interference involves light waves from two coherent sources (the slits) overlapping and creating a pattern of alternating bright and dark fringes. The condition for bright fringes (constructive interference) is that the difference in the path lengths from the slits to a point on the screen is an integer multiple of the wavelength, expressed as d sin? = m?, where d is the separation between the slits, ? is the angle of that fringe relative to the central maximum, and m is the order number.

Single-Slit Diffraction

Single-slit diffraction arises because each slit has a finite width, which causes light to spread out and interfere with itself. This forms an envelope over the interference pattern. The minima in the diffraction pattern occur when the slit width a satisfies the condition a sin? = m? (with m being a non-zero integer), leading to dark regions that can suppress fringes from the interference pattern.

Combined Diffraction-Interference Patterns

When light passes through two finite-width slits, the resulting pattern is a superposition of both double-slit interference and single-slit diffraction. This means that while the double-slit structure produces a rapid sequence of bright and dark fringes, the single-slit diffraction envelope modulates their intensities. In certain scenarios, an interference maximum may coincide with a diffraction minimum, reducing or nullifying the expected brightness of that fringe.

Small Angle Approximation

In many optical experiments, including interference/diffraction setups, the angles involved are small enough that sin? and tan? can be approximated as ? (in radians). This simplification, where sin? ? tan? ? y/L (with y being the distance on the screen from the central maximum and L the distance from the slits to the screen), facilitates easier calculation of fringe positions and analyses of the interference and diffraction conditions.
