Mx25
6=1.6x
2.6×105
= 1.538×104 M
120=1.538×104 M
Component shown was machined from AISI
1040 Cold Rolled. D = 1.000 in., d = 0.625 in.,
Fillet between the major and minor diameter
sections; r = 0.0625 in, at x = 4.75 in. from C.
The length of AC is 71½ inches.
10 = 160 lbs
If a load of P = (150 +YZ) lbs is applied at C,
determine the factor of safety with respect to
failure by yield in the fillet at B.
Mmax = 7.8×105 N-mm
