Determine the equivalent resistance, Req, across the 20-volt source by collapsing the circuit using series and parallel resistor combinations reduction showing each step individually. Redraw the circuit for each.
B.) Determine I, giving its units, using Ohm's Law. (Redraw the appropriate circuit from part (a) used to solve for I.) Circle your answer:
-2 mA
-6 mA
10 mA
3 mA
-1 mA
C.) Determine V2, giving its units, using Voltage Division. (Redraw the appropriate circuit from part (a) used to solve for V2.) Circle your answer:
-2 V
4 V
-6 V
8 V
-12 V
D.) Determine Is, giving its units, using Current Division. Redraw the appropriate circuit from part (a) used to solve for Is. Circle your answer:
1 mA
-6 mA
3/2 mA
-4/3 mA
2/3 mA
E.) Determine the Power associated with the 20-volt source, giving its units. (Redraw the appropriate circuit from part (a) used to solve for this Power.) Circle your answer:
3/16 mW
4 W
-80/3 mW
8 W
Problem ms a Set up the circuit f
9KSZ WW 12KSL 12KS. Va W W + v19 V
V3
