1. The output e.m.f. from a chromel-alumel thermocouple (type K), with its reference junction maintained at 0°C, is 12.207 mV. What is the measured temperature?
2. The output e.m.f. from a nicrosil-nisil thermocouple (type N), with its reference junction maintained at 0°C, is 4.21 mV. What is the measured temperature?
3. A platinum/10% rhodium-platinum (type S) thermocouple is used to measure the temperature of a furnace. The output e.m.f., with the reference junction maintained at 50°C, is 5.975 mV. What is the temperature of the furnace?
4. In a particular industrial situation, a nicrosil-nisil thermocouple with nicrosil-nisil extension wires is used to measure the temperature of a fluid. In connecting up this measurement system, the instrumentation engineer responsible has inadvertently interchanged the extension wires from the thermocouple. The ends of the extension wires are held at a reference temperature of 0°C and the output e.m.f. measured is 21.0 mV. If the junction between the thermocouple and extension wires is at a temperature of 50°C, what temperature of fluid is indicated and what is the true fluid temperature?
