3 0/1 point Consider the circuit shown below with the following parameters: $I_S = 0.4 A,$ $C = 220 \mu F,$ $R_1 = 80 \Omega,$ $R_2 = 80 \Omega,$ $R_3 = 70 \Omega.$ The switch in this circuit has remain closed for a long time prior to $t = 0$, and at $t = 0$ the switch is opened. Determine the indicated current $i$ (in mA) at the instant just after $t = 0$, i.e., $i(0^+)$. (no answer) Correct Answer: -200.0000
