\begin{tabular}{|l|l|l|l} Year & Coal & Petroleum & \begin{tabular}{l} Natural \\ Gas \end{tabular} \\ \hline 1980 & 1161.562 & \( \mathbf{2 4 5 . 9 9 4 2} \) & \( \underline{346.2399} \) \\ \hline 1990 & 1594.011 & \( \mathbf{1 2 6 . 6 2 1 1} \) & \( \underline{372.7652} \) \\ \hline 2000 & 1966.265 & 111.221 & \( \underline{601.0382} \) \\ \hline 2005 & 2040.913 & \( \mathbf{1 1 5 . 4 2 6 4} \) & \( \underline{751.8189} \) \\ \hline 2010 & 2217.555 & \( \mathbf{1 0 4 . 8 1 8 2} \) & \( \underline{773.8234} \) \\ \hline 2020 & 2504.786 & \( \mathbf{1 0 6 . 6 7 9 9} \) & 1102.762 \\ \hline 2030 & 3380.674 & \( \mathbf{1 1 4 . 6 7 4 1} \) & \( \underline{992.7706} \) \\ \hline & & & \\ \hline \end{tabular} Data from U.S. Department of Energy. 13.19 Assuming an average 35\% efficiency for power plants and a heating value of approximately \( 1000 \mathrm{Btu} / \mathrm{ft}^{3}(22,000 \mathrm{Btu} / \mathrm{lbm}) \), calculate the amount of natural gas required in \( \mathrm{ft}^{3} \) and \( \mathrm{lbm} \) for generating electricity for each year shown in the table.
Added by Tom
Close
Step 1
To do this, we need to multiply the energy consumption of natural gas in each year by the efficiency of power plants (35%). For 1980: Electricity generated = Natural gas consumption * Efficiency Electricity generated = 346.2399 billion kWh * 0.35 = 121.186965 Show more…
Show all steps
Your feedback will help us improve your experience
Mayukh Banik and 69 other Physics 102 Electricity and Magnetism educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
A coal fired power plant has a rated power of 800 MWe. It works at 90% capacity, i.e. 90% of the hours in the year, at a thermal efficiency of 36%. The used coal has a HHV (higher heating value) = 9,420 Btu/lb and composition: 54.6% C 0.4% S 13.2% O2 1% N2. 3.8% H2 1. How much electricity does the power plant produce per year (kWh/y)? 2. How much coal does the power plant consume per year (ton/y)? 3. Assuming no emission reduction techniques are used, how much NOx does the power plant emit per year (ton/y) if the emission factor is 24 lb NOx/ton of coal? 4. If the power plant uses a limestone wet scrubber with a SOx reduction efficiency of 92%, how much SOx does the power plant emit per year (ton/y) if the emission factor is 35*S lb SOx/ton of coal where S is the % of sulphur in the coal (no need to convert to units, e.g. 0.004)? 5. If a carbon tax is imposed at $50 per ton of CO2 emitted, estimate the additional cost per kWh for the carbon tax.
Mayukh B.
An old coal-fired power plant runs with a heat rate of 9000 Btu/kWh. The energy content (i.e., heating value or specific energy) of the coal is known to be 24,000 kJ/kg. The coal content includes 62% carbon, 2% sulfur, and 10% unburnable minerals (i.e., ash). (a) What is the fuel rate of the coal [kg/kWh]? (b) What is the carbon emission rate [kg C/kWh]? What is the carbon dioxide emission rate [kg CO2/kWh]? (c) What is the sulfur emission rate [kg S/kWh]? What is the sulfur dioxide emission rate [kg SO2/kWh]? (d) If 70% of the ash is released as particulate matter from the stack (called "fly ash"), what is the uncontrolled particulate emission rate [kg ash/kWh]? (e) What is the efficiency of the power plant?
Sri K.
A typical coal-fired power plant generates $1000 \mathrm{MW}$ of usable power at an overall thermal efficiency of $37 \%$. (a) What is the rate of heat input to the plant? (b) The plant burns anthracite coal, which has a heat of combustion of $2.65 \times 10^{7} \mathrm{~J} / \mathrm{kg} .$ How much coal does the plant use per day, if it operates continuously? (c) At what rate is heat ejected into the cool reservoir, which is the nearby river? (d) The river is at $18.0^{\circ} \mathrm{C}$ before it reaches the power plant and $18.4^{\circ} \mathrm{C}$ after it has received the plant's waste heat. Calculate the river's flow rate, in cubic meters per second. (e) By how much does the river's entropy increase each second?
