00:01
Hello students, from the question we know that equivalent resistance is in the series combination.
00:08
Equivalent resistance is in the series combination.
00:15
So we will add all the resistance values.
00:19
So the total equivalent resistance in a series combination will be 12570 ohms.
00:30
Now we are going to find out the current i equals to v by equivalent resistance.
00:41
So voltage will be 8 and the equivalent resistance will be 12570.
00:47
So the current value will be i equals to 0 .636 milli amps.
00:58
Next we are going to find out the individual voltage for all resistance.
01:03
So we know the formula for the voltage that is v is equals to rir ir.
01:11
According to this we are going to find out each value i mean each voltage value.
01:18
So vr1 is equals to 3 .3 into 3 .3 into 0 .636.
01:32
The value will be 2 .1 volt.
01:41
Next vr2 is equals to 6 .2 into 0 .636...
