Required information
Problem 03.028 - Particle equilibrium in a pulley system - DEPENDENT MULTI-PART PROBLEM - ASSIGN ALL PARTS
The symmetric cable and pulley arrangement shown is used to lift a fragile architectural stone beam. The only significant mass in the system is the 810 kg mass m of the beam.
NOTE: This is a mult-part question. Once an answer is submitted, you will be unable to return to this part.
ences
◻
Problem 03.028.b - Particle equilibrium in a pulley system
Determine the forces in cables ACB and CDE
The force in cable ACB is ◻ N. (Round the final answer to one decimal place)
The force in cable CDE is ◻ N. (Round the final answer to five decimal places)B
