The differential equation for the computer control feedback system of an electromechanical device is given below. Where u(t) is the input and y(t) is the output of the system. (Note: The transfer function will be G(s)=y(s)/u(s) ). d^3y(t)/dt^2 + 6 d^2y(t)/dt^2 + 9 dy(t)/dt = 9 du(t)/dt + 9u(t) If an input 15 volts supplies to the above system determine the output voltage when natural frequency is 3 rad/s. Enter the output voltage value (volts) in the box below: Answer:
Added by Hayla A.
Close
Step 1
Step 1: Read the question carefully and identify the key information provided. Show more…
Show all steps
Your feedback will help us improve your experience
Pawan Yadav and 53 other Physics 102 Electricity and Magnetism educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Consider the coil shown in the figure below. The voltage supply is equal to: u(t) = i(t)R + dψ(t)/dt Assuming that the inductance of the coil is constant, the above equation is: u(t) = i(t)R + Ldi(t)/dt This is a linear 1st order ODE. What is the response of the current to a change in voltage, assuming zero initial conditions? Develop the system differential equation and use Simulink to find the system's step response.
Madhur L.
The purpose of an Automatic Voltage Regulator is to maintain constant the voltage generated in an electrical power system, despite load and line variations, in an electrical power distribution system. Figure P5.31 shows the block diagram of such a system. Assuming Ka=10, Ta=0.1, Ke=1, Te=0.4, Kg=1, Tg=1, Ks=1, Ts=0.001, and the controller, Gpid=1.6+0.4/s+0.3s, find the closed-loop transfer function T(s) of the system, expressing it as a rational function.
Adi S.
